Cobre

Open infrastructure for power system computation. Built in Rust.

Cobre is an ecosystem of Rust crates for power system analysis and optimization. The first solver vertical implements Stochastic Dual Dynamic Programming (SDDP) for long-term hydrothermal dispatch – a problem central to energy planning in systems with large hydroelectric capacity.

Design goals

• Production-grade HPC: hybrid MPI + thread parallelism, designed for cluster execution via mpiexec
• Reproducible results: deterministic output regardless of rank count, thread count, or input ordering
• Modular architecture: 11 crates with clean boundaries, each independently testable
• Open solver stack: HiGHS LP solver, no proprietary dependencies for core functionality

Current status

Phases 1 through 6 are complete. The ecosystem delivers a full SDDP training pipeline: entity model and topology validation (cobre-core), JSON/Parquet case loading with 5-layer validation (cobre-io), LP solver abstraction with HiGHS backend and warm-start basis management (cobre-solver), pluggable communication with MPI and local backends (cobre-comm), PAR(p) inflow models with deterministic correlated scenario generation (cobre-stochastic), and the SDDP training loop with forward/backward passes, Benders cut generation, cut synchronization, convergence monitoring, and composite stopping rules (cobre-sddp) – verified by 1490 tests across the workspace. Implementation continues through the 8-phase build sequence, with Phase 7 (simulation + output) as the next candidate.

Quick links

Installation

This page gets you to a working cobre installation in the shortest path possible. For alternative methods — including cargo install, building from source, and the full platform support table — see Installation (User Guide).

Fastest Path: Pre-built Binary

Download and install the pre-built binary for your platform with a single command.

Linux and macOS

curl --proto '=https' --tlsv1.2 -LsSf https://github.com/cobre-rs/cobre/releases/latest/download/cobre-cli-installer.sh | sh

Windows (PowerShell)

powershell -ExecutionPolicy Bypass -c "irm https://github.com/cobre-rs/cobre/releases/latest/download/cobre-cli-installer.ps1 | iex"

The installer places cobre in $CARGO_HOME/bin (typically ~/.cargo/bin). Ensure that directory is in your PATH.

Verify the Installation

cobre version

Expected output:

cobre   v0.1.0
solver: HiGHS
comm:   local
zstd:   enabled
arch:   x86_64-linux
build:  release (lto=thin)

The exact version, arch, and build fields will vary by platform and release.

Next Steps

• Quickstart — run your first study in three commands
• Installation (User Guide) — cargo install, build from source, and platform table

Quickstart

This page takes you from zero to a completed SDDP study in three commands using the built-in 1dtoy template. The template models a single-bus hydrothermal system with one hydro plant and two thermal units over a 4-stage finite planning horizon — small enough to run in seconds, complete enough to demonstrate every stage of the workflow.

If you have not installed Cobre yet, start with Installation.

Step 1: Scaffold a Case Directory

cobre init --template 1dtoy my_first_study

Cobre writes 10 input files into a new my_first_study/ directory and prints a summary to stderr:

 ━━━━━━━━━━━●
 ━━━━━━━━━━━●⚡  COBRE v0.1.0
 ━━━━━━━━━━━●   Power systems in Rust

Created my_first_study case directory from template '1dtoy':

  ✔ config.json                    Algorithm configuration: training (forward passes, stopping rules) and simulation settings
  ✔ initial_conditions.json        Initial reservoir storage volumes for each hydro plant at the start of the planning horizon
  ✔ penalties.json                 Global penalty costs for constraint violations (deficit, excess, spillage, storage bounds, etc.)
  ✔ stages.json                    Planning horizon definition: policy graph type, discount rate, stage dates, time blocks, and scenario counts
  ✔ system/buses.json              Electrical bus definitions with deficit cost segments
  ✔ system/hydros.json             Hydro plant definitions: reservoir bounds, outflow limits, turbine model, and generation limits
  ✔ system/lines.json              Transmission line definitions (empty in this single-bus example)
  ✔ system/thermals.json           Thermal plant definitions with piecewise cost segments and generation bounds
  ✔ scenarios/inflow_seasonal_stats.parquet  Seasonal PAR(p) statistics for hydro inflow scenario generation (mean, std, lag correlations)
  ✔ scenarios/load_seasonal_stats.parquet    Seasonal PAR(p) statistics for electrical load scenario generation (mean, std, lag correlations)

Next steps:
  -> cobre validate my_first_study
  -> cobre run my_first_study --output my_first_study/results

The directory structure is:

my_first_study/
  config.json
  initial_conditions.json
  penalties.json
  stages.json
  system/
    buses.json
    hydros.json
    lines.json
    thermals.json
  scenarios/
    inflow_seasonal_stats.parquet
    load_seasonal_stats.parquet

Step 2: Validate the Case

cobre validate my_first_study

The validation pipeline checks all five layers — schema, references, physical feasibility, stochastic consistency, and solver feasibility — and prints entity counts on success:

Valid case: 1 buses, 1 hydros, 2 thermals, 0 lines
  buses: 1
  hydros: 1
  thermals: 2
  lines: 0

If any layer fails, Cobre prints each error prefixed with error: and exits with code 1. The 1dtoy template always passes validation.

Step 3: Run the Study

cobre run my_first_study --output my_first_study/results

Cobre runs the SDDP training loop (128 iterations, 1 forward pass each) followed by a simulation pass (100 scenarios). Output is written to my_first_study/results/. The banner, a progress bar, and a post-run summary are printed to stderr:

 ━━━━━━━━━━━●
 ━━━━━━━━━━━●⚡  COBRE v0.1.0
 ━━━━━━━━━━━●   Power systems in Rust

Training complete in 3.2s (128 iterations, converged at iter 94)
  Lower bound:  142.3 $/stage
  Upper bound:  143.1 +/- 1.2 $/stage
  Gap:          0.6%
  Cuts:         94 active / 94 generated
  LP solves:    512

Simulation complete (100 scenarios)
  Completed: 100  Failed: 0

Output written to my_first_study/results/

Exact numerical values (bounds, gap, cut counts, timing) will vary across runs because scenario sampling is stochastic. The gap and iteration count depend on the random seed and the convergence tolerance configured in config.json.

The results directory contains Hive-partitioned Parquet files for costs, hydro dispatch, thermal dispatch, and bus balance, plus a FlatBuffers policy checkpoint:

my_first_study/results/
  policy/
    cuts/
      stage_000.bin  ...  stage_003.bin
    basis/
      stage_000.bin  ...  stage_003.bin
    metadata.json
  simulation/
    costs/
    hydros/
    thermals/
    buses/

What’s Next

You have completed a full SDDP study from case setup to results. The following pages go deeper into how the case is structured and how to interpret the output:

• Anatomy of a Case — what each input file controls
• Understanding Results — how to read Parquet output and convergence metrics
• CLI Reference — all flags, subcommands, and exit codes
• Configuration — every config.json field documented

Anatomy of a Case

A Cobre case directory is a self-contained folder of input files. When you run cobre run or cobre validate, the first thing Cobre does is call load_case on that directory. load_case reads every file, runs the five-layer validation pipeline (schema, references, physical feasibility, stochastic consistency, solver feasibility), and produces a fully-validated System object ready for the solver.

This page walks through every file in the 1dtoy example, explaining what each field controls and why it matters. The example lives in examples/1dtoy/ in the repository and is also available via cobre init --template 1dtoy.

For the complete field-by-field schema reference, see Case Format Reference.

Directory Structure

The 1dtoy case contains 10 input files across three directories:

1dtoy/
  config.json
  initial_conditions.json
  penalties.json
  stages.json
  system/
    buses.json
    hydros.json
    lines.json
    thermals.json
  scenarios/
    inflow_seasonal_stats.parquet
    load_seasonal_stats.parquet

The four root-level files configure the solver and define the time horizon. The system/ subdirectory holds the power system entities. The scenarios/ subdirectory holds the stochastic input data that drives scenario generation.

Root-Level Files

config.json

config.json controls all solver parameters: how many training iterations to run, when to stop, whether to follow training with a simulation pass, and more.

{
  "version": "1.0.0",
  "training": {
    "forward_passes": 1,
    "stopping_rules": [
      {
        "type": "iteration_limit",
        "limit": 128
      }
    ]
  },
  "simulation": {
    "enabled": true,
    "num_scenarios": 100
  }
}

version is an informational string; it does not affect behavior.

The training section is mandatory. forward_passes: 1 means each training iteration draws one scenario trajectory. The stopping_rules array must contain at least one iteration_limit rule. Here the solver stops after 128 iterations. For production studies you would typically also add a convergence-based stopping rule such as bound_stalling, but for a small tutorial case an iteration limit is sufficient.

The simulation section is optional and defaults to disabled. Here it is enabled with 100 scenarios. After training completes, Cobre evaluates the trained policy over 100 independently sampled scenarios and writes the results to the output directory.

For the full list of configuration options, see Configuration.

penalties.json

penalties.json defines the global penalty cost defaults. These costs are added to the LP objective whenever a physical constraint is violated in a soft-constraint sense — for example, when demand cannot be fully served (deficit) or when a reservoir bound is violated. Setting these costs high relative to actual generation costs ensures that violations are used as a last resort rather than a cheap dispatch option.

{
  "bus": {
    "deficit_segments": [
      {
        "depth_mw": 500.0,
        "cost": 1000.0
      },
      {
        "depth_mw": null,
        "cost": 5000.0
      }
    ],
    "excess_cost": 100.0
  },
  "line": {
    "exchange_cost": 2.0
  },
  "hydro": {
    "spillage_cost": 0.01,
    "fpha_turbined_cost": 0.05,
    "diversion_cost": 0.1,
    "storage_violation_below_cost": 10000.0,
    "filling_target_violation_cost": 50000.0,
    "turbined_violation_below_cost": 500.0,
    "outflow_violation_below_cost": 500.0,
    "outflow_violation_above_cost": 500.0,
    "generation_violation_below_cost": 1000.0,
    "evaporation_violation_cost": 5000.0,
    "water_withdrawal_violation_cost": 1000.0
  },
  "non_controllable_source": {
    "curtailment_cost": 0.005
  }
}

The bus.deficit_segments array defines a piecewise-linear deficit cost curve. The first segment covers the first 500 MW of unserved energy at 1000 $/MWh. Beyond 500 MW, the cost rises to 5000 $/MWh (the segment with depth_mw: null is always the final unbounded tier). The two-tier structure mimics a typical Value of Lost Load model where the first tranche represents interruptible load and the second represents non-interruptible load. excess_cost penalizes over-injection at 100 $/MWh.

Hydro penalty costs cover a range of operational constraint violations. The low spillage_cost (0.01 $/hm3) makes spillage the cheapest way to release water when turbine capacity is exhausted. The high storage_violation_below_cost (10,000 $/hm3) and filling_target_violation_cost (50,000 $/hm3) make reservoir bound violations extremely costly, ensuring the solver strongly avoids them.

Individual entities can override these global defaults in their own JSON files using a penalties block. The reference page documents all override options.

stages.json

stages.json defines the temporal structure of the study: the sequence of planning stages, the load blocks within each stage, the number of scenarios to sample at each stage during training, and the policy graph horizon type.

{
  "policy_graph": {
    "type": "finite_horizon",
    "annual_discount_rate": 0.12
  },
  "stages": [
    {
      "id": 0,
      "start_date": "2024-01-01",
      "end_date": "2024-02-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 744
        }
      ],
      "num_scenarios": 10
    },
    {
      "id": 1,
      "start_date": "2024-02-01",
      "end_date": "2024-03-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 696
        }
      ],
      "num_scenarios": 10
    },
    {
      "id": 2,
      "start_date": "2024-03-01",
      "end_date": "2024-04-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 744
        }
      ],
      "num_scenarios": 10
    },
    {
      "id": 3,
      "start_date": "2024-04-01",
      "end_date": "2024-05-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 720
        }
      ],
      "num_scenarios": 10
    }
  ]
}

policy_graph.type: "finite_horizon" means the planning horizon is a linear sequence of stages with no cyclic structure and zero terminal value after the last stage. The annual_discount_rate: 0.12 applies a 12% annual discount to future stage costs.

The stages array defines four monthly stages covering January through April 2024. Each stage has a single load block named SINGLE that spans the entire month. The hours values match the actual number of hours in each calendar month (744 for January, 696 for February in 2024, and so on). These hours are used when converting power (MW) to energy (MWh) in the LP objective.

num_scenarios: 10 means 10 scenario trajectories are sampled at each stage during training forward passes. A small number like 10 is sufficient for a tutorial; real studies typically use 50 or more.

initial_conditions.json

initial_conditions.json provides the reservoir storage levels at the beginning of the study. Every hydro plant that participates in the study must have an entry here.

{
  "storage": [
    {
      "hydro_id": 0,
      "value_hm3": 83.222
    }
  ],
  "filling_storage": []
}

storage covers operating reservoirs: plants that both generate power and store water between stages. hydro_id: 0 corresponds to UHE1 defined in system/hydros.json. The initial storage is 83.222 hm³, which is about 8.3% of the 1000 hm³ maximum capacity — a low-storage starting condition that forces the solver to balance generation against the risk of running dry.

filling_storage covers filling reservoirs — reservoirs that do not generate power but feed downstream plants. The 1dtoy case has no filling reservoirs, so this array is empty. It must still be present (even if empty) to satisfy the schema.

system/ Files

system/buses.json

Buses are the nodes of the electrical network. Every generator and load is connected to a bus. The bus balance constraint ensures that injections equal withdrawals at every bus in every LP solve.

{
  "buses": [
    {
      "id": 0,
      "name": "SIN",
      "deficit_segments": [
        {
          "depth_mw": null,
          "cost": 1000.0
        }
      ]
    }
  ]
}

The 1dtoy case has a single bus named SIN (Sistema Interligado Nacional, the Brazilian interconnected system). A single-bus model treats the entire system as one copper-plate node: there are no transmission constraints.

The bus-level deficit_segments here overrides the global default from penalties.json with a simpler single-tier structure: unlimited deficit at 1000 $/MWh. When an entity-level override is present, it takes precedence over the global default.

system/lines.json

Transmission lines connect pairs of buses and carry power flows subject to capacity limits. In a single-bus model, no lines are needed.

{
  "lines": []
}

The file must be present even if the lines array is empty. The validator checks for the file and would raise a schema error if it were absent.

system/hydros.json

Hydro plants have a reservoir (water storage), a turbine (converts water flow to electricity), and optional cascade linkage to downstream plants.

{
  "hydros": [
    {
      "id": 0,
      "name": "UHE1",
      "bus_id": 0,
      "downstream_id": null,
      "reservoir": {
        "min_storage_hm3": 0.0,
        "max_storage_hm3": 1000.0
      },
      "outflow": {
        "min_outflow_m3s": 0.0,
        "max_outflow_m3s": 50.0
      },
      "generation": {
        "model": "constant_productivity",
        "productivity_mw_per_m3s": 1.0,
        "min_turbined_m3s": 0.0,
        "max_turbined_m3s": 50.0,
        "min_generation_mw": 0.0,
        "max_generation_mw": 50.0
      }
    }
  ]
}

UHE1 connects to bus 0 (SIN). downstream_id: null means it is a tailwater plant — there is no plant downstream that receives its outflow.

The reservoir block defines storage bounds in hm³ (cubic hectometres). UHE1 can hold between 0 and 1000 hm³. The minimum of 0 means the reservoir can be fully emptied, which is common for run-of-river-adjacent plants.

The outflow block limits total outflow (turbined + spilled) to 50 m³/s maximum. This is a physical constraint representing the river channel capacity below the dam.

The generation block uses "constant_productivity", the simplest turbine model: generation (MW) equals turbined flow (m³/s) times the productivity_mw_per_m3s factor. Here the factor is 1.0, so 1 m³/s of turbined flow yields 1 MW. The turbine can pass between 0 and 50 m³/s, and the resulting generation is bounded between 0 and 50 MW.

system/thermals.json

Thermal plants are dispatchable generators with a fixed cost per MWh. The piecewise cost structure allows modeling fuel cost curves by defining multiple capacity segments at increasing costs.

{
  "thermals": [
    {
      "id": 0,
      "name": "UTE1",
      "bus_id": 0,
      "cost_segments": [
        {
          "capacity_mw": 15.0,
          "cost_per_mwh": 5.0
        }
      ],
      "generation": {
        "min_mw": 0.0,
        "max_mw": 15.0
      }
    },
    {
      "id": 1,
      "name": "UTE2",
      "bus_id": 0,
      "cost_segments": [
        {
          "capacity_mw": 15.0,
          "cost_per_mwh": 10.0
        }
      ],
      "generation": {
        "min_mw": 0.0,
        "max_mw": 15.0
      }
    }
  ]
}

Both thermal plants connect to bus 0. UTE1 is the cheaper unit at 5 $/MWh and UTE2 costs 10 $/MWh. Both are limited to 15 MW maximum dispatch. In the LP, Cobre will always prefer UTE1 over UTE2 and prefer both over deficit (1000 $/MWh), creating a natural merit-order dispatch.

Each thermal has a single cost segment covering its entire capacity. For plants with variable heat rates you would add additional segments — for example, { "capacity_mw": 10.0, "cost_per_mwh": 8.0 } followed by { "capacity_mw": 5.0, "cost_per_mwh": 12.0 } to model a plant that becomes progressively more expensive at higher output.

scenarios/ Files

The scenarios/ directory holds Parquet files that parameterize the stochastic models used to generate inflow and load scenarios during training and simulation. Unlike the JSON files, these are binary columnar files that cannot be inspected with a text editor.

scenarios/inflow_seasonal_stats.parquet

This file contains the seasonal mean and standard deviation of historical inflows for each (hydro plant, stage) pair, plus the autoregressive order for the PAR(p) model. Cobre uses these statistics to fit a periodic autoregressive model that generates correlated inflow scenarios across stages.

Expected columns:

The 1dtoy file has 4 rows, one for each stage, for the single hydro plant UHE1 (hydro_id = 0). When ar_order > 0, Cobre also looks for an inflow_ar_coefficients.parquet file containing the lag coefficients. The 1dtoy case uses ar_order = 0 (white noise), so no coefficients file is needed.

To inspect a Parquet file on your machine, use any of:

import polars as pl
df = pl.read_parquet("scenarios/inflow_seasonal_stats.parquet")
print(df)

import pandas as pd
df = pd.read_parquet("scenarios/inflow_seasonal_stats.parquet")
print(df)

-- DuckDB
SELECT * FROM read_parquet('scenarios/inflow_seasonal_stats.parquet');

scenarios/load_seasonal_stats.parquet

This file contains the seasonal statistics for electrical load at each bus. It drives the stochastic load model that generates demand scenarios during training and simulation.

Expected columns:

The 1dtoy file has 4 rows, one for each stage, for the single bus SIN (bus_id = 0). The load mean and standard deviation determine how much demand the system must serve in each scenario and how uncertain that demand is.

What’s Next

Now that you understand what each file does, the next page walks you through creating a case from scratch:

• Building a System — step-by-step guide to creating every file
• Case Format Reference — complete field-by-field schema
• Configuration — all config.json fields documented

Building a System

This page walks you through creating a minimal case directory from scratch, explaining why each file exists and what each field controls. The target is a single-bus hydrothermal system identical to the 1dtoy template: one bus, one hydro plant, two thermal units, and a four-month planning horizon.

If you want to start from a working template instead, use:

cobre init --template 1dtoy my_study

This page is for users who want to understand the structure of every file before touching real data.

Prerequisites

Create an empty directory and enter it:

mkdir my_study
cd my_study
mkdir system

You will need 8 JSON files. By the end of this guide your directory will look like:

my_study/
  config.json
  initial_conditions.json
  penalties.json
  stages.json
  system/
    buses.json
    hydros.json
    lines.json
    thermals.json

The scenarios/ subdirectory is optional for a minimal case. Cobre can generate white-noise inflow and load scenarios using only the stage definitions, without Parquet statistics files.

Step 1: Create config.json

config.json tells Cobre how to run the study. At minimum it needs a training section with a forward_passes count and at least one stopping_rules entry.

Create my_study/config.json:

{
  "training": {
    "forward_passes": 1,
    "stopping_rules": [
      {
        "type": "iteration_limit",
        "limit": 128
      }
    ]
  },
  "simulation": {
    "enabled": true,
    "num_scenarios": 100
  }
}

forward_passes controls how many scenario trajectories are drawn per training iteration. Start with 1 for fast iteration during case development; increase to 50 or more for production runs where you want lower variance per iteration.

stopping_rules must contain at least one iteration_limit entry. The solver will run until one of the configured rules triggers. Here it stops after 128 iterations regardless of convergence. You can add a second rule — for example, { "type": "time_limit", "seconds": 300 } — and the solver will stop when either condition is met.

The simulation block is optional. When enabled: true, Cobre runs a post-training simulation pass using num_scenarios independently sampled scenarios and writes dispatch results to Parquet files.

For the full list of configuration options including warm-start, cut selection, and output controls, see Configuration.

Step 2: Create stages.json

stages.json defines the time horizon. Each stage represents a planning period. The solver builds one LP sub-problem per stage per scenario trajectory.

Create my_study/stages.json:

{
  "policy_graph": {
    "type": "finite_horizon",
    "annual_discount_rate": 0.12
  },
  "stages": [
    {
      "id": 0,
      "start_date": "2024-01-01",
      "end_date": "2024-02-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 744
        }
      ],
      "num_scenarios": 10
    },
    {
      "id": 1,
      "start_date": "2024-02-01",
      "end_date": "2024-03-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 696
        }
      ],
      "num_scenarios": 10
    },
    {
      "id": 2,
      "start_date": "2024-03-01",
      "end_date": "2024-04-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 744
        }
      ],
      "num_scenarios": 10
    },
    {
      "id": 3,
      "start_date": "2024-04-01",
      "end_date": "2024-05-01",
      "blocks": [
        {
          "id": 0,
          "name": "SINGLE",
          "hours": 720
        }
      ],
      "num_scenarios": 10
    }
  ]
}

policy_graph.type: "finite_horizon" is the correct choice for a planning horizon with a definite end date and no cycling. The annual_discount_rate is applied to discount future stage costs back to present value. A rate of 0.12 means costs one year in the future are worth 88% of present costs.

Each stage entry needs an id (0-indexed integer), a start_date and end_date in ISO 8601 format, an array of blocks, and a num_scenarios count.

The blocks array subdivides a stage into load periods. A single block named SINGLE that spans all the hours of the month is the simplest choice. More detailed studies use two or three blocks (peak/off-peak/overnight) to capture intra-stage load variation. The hours value must equal the actual number of hours in the stage: these hours convert MW dispatch levels to MWh costs in the LP objective.

num_scenarios is the number of inflow/load scenario trajectories sampled at each stage during training. More scenarios per iteration produce less-noisy cut estimates at the cost of more LP solves per iteration.

Step 3: Create penalties.json

Penalty costs define how much the solver pays when it cannot satisfy a constraint without violating a physical bound. High penalties make violations expensive so the solver avoids them; low penalties on minor constraints (like spillage) allow the solver to use flexibility when needed.

Create my_study/penalties.json:

{
  "bus": {
    "deficit_segments": [
      {
        "depth_mw": 500.0,
        "cost": 1000.0
      },
      {
        "depth_mw": null,
        "cost": 5000.0
      }
    ],
    "excess_cost": 100.0
  },
  "line": {
    "exchange_cost": 2.0
  },
  "hydro": {
    "spillage_cost": 0.01,
    "fpha_turbined_cost": 0.05,
    "diversion_cost": 0.1,
    "storage_violation_below_cost": 10000.0,
    "filling_target_violation_cost": 50000.0,
    "turbined_violation_below_cost": 500.0,
    "outflow_violation_below_cost": 500.0,
    "outflow_violation_above_cost": 500.0,
    "generation_violation_below_cost": 1000.0,
    "evaporation_violation_cost": 5000.0,
    "water_withdrawal_violation_cost": 1000.0
  },
  "non_controllable_source": {
    "curtailment_cost": 0.005
  }
}

The bus.deficit_segments array must end with a segment where depth_mw is null. This unbounded final segment ensures the LP always has a feasible solution even when generation capacity is insufficient to cover load. All four top-level sections (bus, line, hydro, non_controllable_source) are required even if your system contains none of that entity type.

Individual penalty values can be overridden per entity by adding a penalties block inside any entity definition in the system/ files. The global values here serve as the default for any entity that does not specify its own.

Step 4: Create system/buses.json

A bus is an electrical node. All generators and loads connect to a bus. Every system needs at least one bus.

Create my_study/system/buses.json:

{
  "buses": [
    {
      "id": 0,
      "name": "SIN",
      "deficit_segments": [
        {
          "depth_mw": null,
          "cost": 1000.0
        }
      ]
    }
  ]
}

id must be a unique non-negative integer. name is a human-readable label used in output files and validation messages. The deficit_segments override here replaces the global deficit curve from penalties.json for this specific bus. A single unbounded segment at 1000 $/MWh is the simplest possible deficit model.

If you omit deficit_segments from a bus, Cobre uses the global default from penalties.json for that bus. Explicit overrides are useful when different buses have different Value of Lost Load characteristics.

Step 5: Create system/lines.json

Transmission lines connect pairs of buses and impose flow limits between them. A single-bus system has no lines.

Create my_study/system/lines.json:

{
  "lines": []
}

The file must exist even with an empty array. The validator checks that the file is present and that its schema is valid. If you later add a second bus, you can add lines here by specifying source_bus_id, target_bus_id, direct_mw, and reverse_mw for each line.

Step 6: Create system/thermals.json

Thermal plants are dispatchable generators. They have a fixed cost per MWh of generation and physical capacity bounds. Add them in increasing cost order as a matter of convention, though the LP will find the optimal merit order regardless.

Create my_study/system/thermals.json:

{
  "thermals": [
    {
      "id": 0,
      "name": "UTE1",
      "bus_id": 0,
      "cost_segments": [
        {
          "capacity_mw": 15.0,
          "cost_per_mwh": 5.0
        }
      ],
      "generation": {
        "min_mw": 0.0,
        "max_mw": 15.0
      }
    },
    {
      "id": 1,
      "name": "UTE2",
      "bus_id": 0,
      "cost_segments": [
        {
          "capacity_mw": 15.0,
          "cost_per_mwh": 10.0
        }
      ],
      "generation": {
        "min_mw": 0.0,
        "max_mw": 15.0
      }
    }
  ]
}

bus_id: 0 connects both plants to the SIN bus. The cost_segments array defines a piecewise-linear cost curve. Each segment has a capacity_mw and a cost_per_mwh. With a single segment, the entire capacity is available at the same cost. The segment capacities should sum to generation.max_mw.

generation.min_mw: 0.0 means the plant can be turned off completely. A non-zero minimum would represent a must-run commitment constraint. max_mw caps the generation level and should equal the sum of all cost_segments capacities.

The bus_id must reference a bus id defined in buses.json. The validator will catch any broken reference and report it as a reference integrity error.

Step 7: Create system/hydros.json

Hydro plants have three components: a reservoir (state variable between stages), a turbine (converts water flow to electricity), and optional cascade linkage to downstream plants.

Create my_study/system/hydros.json:

{
  "hydros": [
    {
      "id": 0,
      "name": "UHE1",
      "bus_id": 0,
      "downstream_id": null,
      "reservoir": {
        "min_storage_hm3": 0.0,
        "max_storage_hm3": 1000.0
      },
      "outflow": {
        "min_outflow_m3s": 0.0,
        "max_outflow_m3s": 50.0
      },
      "generation": {
        "model": "constant_productivity",
        "productivity_mw_per_m3s": 1.0,
        "min_turbined_m3s": 0.0,
        "max_turbined_m3s": 50.0,
        "min_generation_mw": 0.0,
        "max_generation_mw": 50.0
      }
    }
  ]
}

downstream_id: null marks UHE1 as a tailwater plant. To model a cascade where plant A flows into plant B, you would set downstream_id: <B's id> on plant A. Cobre enforces that the downstream graph is acyclic.

The reservoir block uses hm³ (cubic hectometres) as the unit for water volume. min_storage_hm3: 0.0 allows the reservoir to empty completely. If your plant has a dead storage (volume below the turbine intake), set min_storage_hm3 to that value.

The outflow block limits total outflow (turbined flow plus spillage). The upper bound max_outflow_m3s: 50.0 models the river channel capacity. Setting a non-zero min_outflow_m3s would represent a minimum ecological flow requirement.

The generation block uses "constant_productivity" which is the only supported model for the current release. The productivity_mw_per_m3s factor converts turbined flow to generated power. Here 1 m³/s yields 1 MW. Real plants typically have productivity factors between 0.5 and 10 depending on the head height.

Step 8: Create initial_conditions.json

Every hydro plant needs an initial reservoir storage value at the start of the study. This is the state the solver uses for stage 0’s water balance equation.

Create my_study/initial_conditions.json:

{
  "storage": [
    {
      "hydro_id": 0,
      "value_hm3": 83.222
    }
  ],
  "filling_storage": []
}

hydro_id: 0 matches UHE1 defined in system/hydros.json. Every hydro plant in the system must have exactly one entry in either storage or filling_storage — not both, not neither. The validator checks this.

value_hm3: 83.222 sets the initial reservoir at about 8.3% of its 1000 hm³ capacity. Choosing a realistic initial condition matters for short horizons because the first few stages will be heavily influenced by whether the reservoir starts full or nearly empty. For multi-year studies the initial condition has less impact on later stages.

filling_storage is for filling reservoirs — reservoirs that accumulate water but do not generate power. The 1dtoy system has none, so this array is empty. It must be present even when empty.

Step 9: Validate Your Case

With all 8 files in place, validate the case to confirm every layer passes:

cobre validate my_study

On success, Cobre prints the entity counts:

Valid case: 1 buses, 1 hydros, 2 thermals, 0 lines
  buses: 1
  hydros: 1
  thermals: 2
  lines: 0

If any validation layer fails, each error is prefixed with error: and the exit code is 1. Common errors at this stage:

• reference error: hydro 0 references bus 99 which does not exist — a bus_id in hydros.json does not match any id in buses.json.
• initial conditions: hydro 0 has no initial storage entry — a hydro plant in hydros.json is missing from initial_conditions.json.
• penalties.json: non_controllable_source section missing — a required top-level section is absent from penalties.json, even if the system has no NCS plants.

Fix each reported error and re-run cobre validate until the exit code is 0.

What’s Next

Your hand-built case is functionally identical to the 1dtoy template. You can run it directly:

cobre run my_study --output my_study/results

To compare your files against the template at any point:

cobre init --template 1dtoy 1dtoy_reference
diff -r my_study 1dtoy_reference

From here, the natural next steps are:

• Understanding Results — how to read the Parquet output files
• Anatomy of a Case — detailed explanation of every field in these files
• Case Format Reference — complete schema with all optional fields
• Configuration — advanced config.json options including warm-start and cut selection

Understanding Results

After cobre run completes, the output directory contains three categories of artifacts: training convergence data, a saved policy checkpoint, and simulation dispatch results. This page explains how to read each category and how to query the results programmatically using cobre report.

If you have not yet run the quickstart, complete Quickstart first — this page references the my_first_study/results/ directory produced by that walkthrough.

The Post-Run Summary

When cobre run finishes, it prints a summary block to stderr. The 1dtoy run from the quickstart produces output similar to:

Training complete in 3.2s (128 iterations, iteration_limit)
  Lower bound:  142.3 $/stage
  Upper bound:  143.1 +/- 1.2 $/stage
  Gap:          0.6%
  Cuts:         384 active / 387 generated
  LP solves:    512

Simulation complete (100 scenarios)
  Completed: 100  Failed: 0

Output written to my_first_study/results/

Exact numerical values vary across runs because scenario sampling is stochastic. The values below are representative of the 1dtoy example; your run will differ slightly.

Lower bound vs. upper bound. The lower bound is the optimizer’s proven best estimate of the minimum achievable cost. The upper bound is the average cost observed when running the current policy over sampled scenarios. When the gap is small, the policy is near-optimal. When the gap is large, running more iterations will typically narrow it further.

Termination reasons. The parenthetical after the iteration count explains why training stopped:

• iteration_limit — the maximum iteration count was reached (the 1dtoy default).
• converged at iter N — a convergence criterion was met at iteration N and training stopped early. This appears when you configure a bound_stalling or similar rule in config.json.

Theory reference: For the mathematical definition of lower and upper bounds, optimality gap, and stopping criteria, see Convergence in the methodology reference.

Output Directory Structure

All artifacts are written under the results directory you specified with --output. The 1dtoy run produces:

my_first_study/results/
  training/
    _manifest.json          Completion manifest: status, iteration count, convergence, cut stats
    metadata.json           Run metadata: configuration snapshot, problem dimensions
    convergence.parquet     Per-iteration convergence metrics (lower bound, upper bound, gap)
    dictionaries/
      codes.json            Integer-to-string code mappings for entity categories
      state_dictionary.json State variable definitions and units
      entities.csv          Entity registry (id, name, type)
      variables.csv         LP variable registry
      bounds.parquet        LP variable bound definitions
    timing/
      iterations.parquet    Per-iteration wall-clock timing broken down by phase
  policy/
    cuts/
      stage_000.bin         FlatBuffers-encoded optimality cuts for stage 0
      stage_001.bin         ... stage 1
      stage_002.bin         ... stage 2
      stage_003.bin         ... stage 3
    basis/
      stage_000.bin         LP basis checkpoints for warm-starting
      stage_001.bin
      stage_002.bin
      stage_003.bin
    metadata.json           Policy metadata: stage count, cut counts per stage
  simulation/
    _manifest.json          Completion manifest: scenario counts
    buses/
      scenario_id=0000/data.parquet
      scenario_id=0001/data.parquet
      ...                   One partition per scenario
    costs/
      scenario_id=0000/data.parquet
      ...
    hydros/
      scenario_id=0000/data.parquet
      ...
    thermals/
      scenario_id=0000/data.parquet
      ...
    inflow_lags/            Inflow lag state data used to initialize scenario chains

The three top-level subdirectories have distinct roles:

• training/ — everything produced during the training loop: convergence history, timing, and the dictionaries needed to interpret LP variable indices.
• policy/ — the trained policy checkpoint. These binary files encode the optimality cuts built during training. They can be used to resume or extend a study.
• simulation/ — the dispatch results from evaluating the trained policy over 100 simulation scenarios.

Training Results

Reading training/_manifest.json

The training manifest is the canonical summary of what happened during training. The 1dtoy run produces:

{
  "version": "2.0.0",
  "status": "complete",
  "started_at": null,
  "completed_at": null,
  "iterations": {
    "max_iterations": null,
    "completed": 128,
    "converged_at": null
  },
  "convergence": {
    "achieved": false,
    "final_gap_percent": 0.0,
    "termination_reason": "iteration_limit"
  },
  "cuts": {
    "total_generated": 387,
    "total_active": 384,
    "peak_active": 384
  },
  "checksum": null,
  "mpi_info": {
    "world_size": 1,
    "ranks_participated": 1
  }
}

Field-by-field explanation:

What “converged” means in practice. A converged run (convergence.achieved: true) means a stopping rule determined that continuing would not meaningfully improve the policy. For the 1dtoy case, the gap reaches near zero within the 128-iteration budget even without an explicit convergence rule, which is why final_gap_percent is 0.0 despite achieved being false — the run hit its iteration limit at a point where the policy was already very tight.

For larger studies, configure a bound_stalling or gap_threshold stopping rule in config.json to stop automatically when the gap stabilizes, rather than running a fixed number of iterations.

Simulation Results

Hive-Partitioned Layout

The simulation output uses Hive partitioning: results are split into one data.parquet file per scenario, stored in a directory named scenario_id=NNNN/. This layout is natively understood by Polars, Pandas (via PyArrow), R’s arrow package, and DuckDB — they can read the entire simulation/costs/ directory as a single table and filter by scenario_id at the storage layer without loading all data into memory.

The four entity categories are:

Results are in Parquet format. To read them, use any columnar data tool:

# Polars — reads all 100 scenarios at once
import polars as pl
df = pl.read_parquet("my_first_study/results/simulation/costs/")
print(df.head())

# Pandas + PyArrow
import pandas as pd
df = pd.read_parquet("my_first_study/results/simulation/costs/")
print(df.head())

-- DuckDB — filter to a single scenario
SELECT * FROM read_parquet('my_first_study/results/simulation/costs/**/*.parquet')
WHERE scenario_id = 0;

# R with arrow
library(arrow)
ds <- open_dataset("my_first_study/results/simulation/costs/")
dplyr::collect(dplyr::filter(ds, scenario_id == 0))

Querying Results with cobre report

cobre report reads the JSON manifests and prints a structured JSON summary to stdout. Use it with jq to extract specific metrics in scripts or CI pipelines.

# Print the full report
cobre report my_first_study/results

The output has this top-level shape:

{
  "output_directory": "/abs/path/to/results",
  "status": "complete",
  "training": { "iterations": {}, "convergence": {}, "cuts": {} },
  "simulation": { "scenarios": {} },
  "metadata": { "run_info": {}, "configuration_snapshot": {} }
}

Practical jq queries

# Extract the final convergence gap
cobre report my_first_study/results | jq '.training.convergence.final_gap_percent'

# Check how many iterations ran
cobre report my_first_study/results | jq '.training.iterations.completed'

# Check simulation scenario counts
cobre report my_first_study/results | jq '.simulation.scenarios'

# Use the status in a CI script: exit non-zero if training failed
status=$(cobre report my_first_study/results | jq -r '.status')
if [ "$status" != "complete" ]; then
  echo "Run did not complete successfully: $status" >&2
  exit 1
fi

# Check convergence was achieved (returns true or false)
cobre report my_first_study/results | jq '.training.convergence.achieved'

For the complete cobre report documentation and all available JSON fields, see CLI Reference.

For a detailed description of every field in every output file, see Output Format Reference.

What’s Next

You have now seen how to run a study and interpret its output. The next page collects pointers to everything you need to go further:

• Next Steps — further reading, guides, and community links
• CLI Reference — all flags, subcommands, and exit codes
• Configuration — every config.json field documented

Next Steps

You have completed the Cobre tutorial: you installed the tool, ran a complete study with the 1dtoy template, inspected the case files, and interpreted the output. This page points you to the resources that go deeper.

Configuration

The config.json file controls every aspect of how training and simulation are run: stopping rules, forward pass counts, simulation scenario counts, and more. The configuration guide documents every field with examples.

• Configuration — complete config.json field reference

System Modeling

The tutorial uses a minimal single-bus, one-hydro, two-thermal system. Real studies model transmission networks, cascaded hydro plants, and many thermal units. The system modeling guides explain every entity type and its parameters.

• Hydro Plants — reservoir bounds, turbine models, cascade linkage
• Thermal Units — piecewise cost curves, generation limits
• Network Topology — buses, transmission lines, and flow constraints

CLI Reference

All subcommands (run, validate, report, version), their flags, exit codes, and environment variables are documented in the CLI reference.

• CLI Reference — subcommand synopsis, options, and examples

Methodology and Theory

The methodology reference describes the mathematical foundations of the solver: the stochastic optimization formulation, the PAR(p) scenario model, the cut management strategy, and the convergence theory. This is the right place to start if you want to understand what the solver is doing, not just how to use it.

• Methodology Reference — full theory documentation (external)

API Documentation

The Rust API for all workspace crates is generated from inline doc comments. To build and open it locally:

cargo doc --workspace --no-deps --open

This opens the documentation for all 10 workspace crates in your browser. The cobre-core crate documents the entity model; cobre-sddp documents the training loop and cut management types.

Contributing

If you find a bug, want to add a feature, or want to improve the documentation, the contributing guide explains how to set up the development environment, run the test suite, and submit a pull request.

• Contributing — development setup, branch conventions, and PR process

Community and Support

• GitHub Repository — source code, releases, and project board
• Issue Tracker — bug reports and feature requests
• Discussions — questions, ideas, and community discussion

Getting Started

Cobre is a power system analysis toolkit built around a production-grade SDDP solver for long-term hydrothermal dispatch planning. It reads a self-contained case directory of JSON and Parquet input files, trains a stochastic dispatch policy, simulates that policy over independent scenarios, and writes Hive-partitioned Parquet output ready for analysis.

This section of the User Guide is the reference path through the software. If you prefer a hands-on walkthrough starting from a working example, the Tutorial is the better starting point.

What You Need

To use pre-built binaries (recommended for most users)

No Rust toolchain or C compiler required. The pre-built binary is statically linked and runs on the following platforms out of the box:

To build from source

Next Steps

Install Cobre

Installation covers all three installation methods: pre-built binary (the fastest path), cargo install from crates.io, and building from source for contributors or unsupported platforms.

Run Your First Study

Your First Study walks through the end-to-end workflow for running a study on a case directory you already have: validate inputs, run the solver, and inspect results with cobre report.

For Hands-On Learners

The Tutorial section provides a step-by-step learning path that starts by installing Cobre, then scaffolds a complete example study using the built-in 1dtoy template, explains the anatomy of a case directory, and shows how to read the output files.

If you have not used Cobre before, starting with the Tutorial and returning to the User Guide as a reference is the recommended approach.

Related Pages

• Installation — all installation methods and platform table
• Your First Study — validate, run, and inspect a study
• Running Studies — full workflow reference with exit codes
• CLI Reference — all subcommands, flags, and environment variables

Installation

Cobre v0.1.0 is a statically linked binary available for five platforms. Choose the method that best fits your environment.

Pre-built Binaries (Recommended)

Fastest for end users. No Rust toolchain or C compiler required.

Linux and macOS

curl --proto '=https' --tlsv1.2 -LsSf https://github.com/cobre-rs/cobre/releases/latest/download/cobre-cli-installer.sh | sh

The installer places the cobre binary in $CARGO_HOME/bin (typically ~/.cargo/bin). Add that directory to your PATH if it is not already present.

Windows (PowerShell)

powershell -ExecutionPolicy Bypass -c "irm https://github.com/cobre-rs/cobre/releases/latest/download/cobre-cli-installer.ps1 | iex"

Supported Platforms

You can also download individual archives directly from the GitHub Releases page.

Verify the Installation

cobre version

Expected output (exact versions and arch will vary):

cobre   v0.1.0
solver: HiGHS
comm:   local
zstd:   enabled
arch:   x86_64-linux
build:  release (lto=thin)

From crates.io

cargo install cobre-cli

Requires Rust 1.85+ and build prerequisites (see Build from Source below). Installs to $CARGO_HOME/bin.

Build from Source

For contributors or unsupported platforms.

Prerequisites

Steps

# Clone the repository
git clone https://github.com/cobre-rs/cobre.git
cd cobre

# Initialize HiGHS submodule (required for the solver backend)
git submodule update --init --recursive

# Build the release binary
cargo build --release -p cobre-cli

The binary is written to target/release/cobre. Optionally install to $CARGO_HOME/bin:

cargo install --path crates/cobre-cli

Verify:

./target/release/cobre version
cargo test --workspace --all-features

Next Steps

• Your First Study — run a complete SDDP study end to end
• Case Directory Format — how to structure input data
• CLI Reference — complete flag and subcommand reference

Your First Study

This page walks through running a complete SDDP study with Cobre from a case directory you already have. It covers the three-step workflow — validate, run, report — explains what each output file contains at a high level, and points you to the right reference pages for deeper analysis.

If you do not yet have a case directory, the Quickstart tutorial shows how to scaffold one from a built-in template using cobre init --template 1dtoy.

Prepare Your Case Directory

A case directory is a self-contained folder that holds all input files for a single power system study. The minimum required structure is:

my_study/
  config.json
  penalties.json
  stages.json
  initial_conditions.json
  system/
    buses.json
    hydros.json
    thermals.json
    lines.json

config.json controls the training algorithm (number of forward passes, stopping rules) and simulation settings. stages.json defines the planning horizon, policy graph type, and time blocks. The system/ files define the physical elements of the power system. scenarios/ holds optional Parquet files with PAR(p) statistics for stochastic inflow and load generation.

For the complete schema of every file, see Case Directory Format.

Validate the Inputs

Before running the solver, validate the case directory to catch input errors early:

cobre validate /path/to/my_study

The validation pipeline runs five layers in sequence: schema correctness, cross-reference consistency (e.g., every plant references a valid bus), physical feasibility (e.g., capacity bounds are non-negative), stochastic consistency (e.g., PAR(p) statistics are well-defined), and solver feasibility (e.g., the LP is bounded). Each layer must pass before the next runs.

On success, Cobre prints entity counts and exits with code 0:

Valid case: 3 buses, 12 hydros, 8 thermals, 4 lines
  buses: 3
  hydros: 12
  thermals: 8
  lines: 4

On failure, each error is printed with an error: prefix and Cobre exits with code 1. Fix all reported errors before proceeding — cobre run runs the same validation pipeline and will exit with code 1 on any validation failure.

Run the Study

cobre run /path/to/my_study

By default, results are written to <CASE_DIR>/output/. To specify a different location:

cobre run /path/to/my_study --output /path/to/results

The run proceeds through four lifecycle stages:

1. Load — reads all input files and runs the validation pipeline.
2. Train — iterates the SDDP forward/backward pass loop until the configured stopping rules are satisfied (gap threshold, iteration limit, or bound stalling).
3. Simulate — evaluates the trained policy over independent out-of-sample scenarios. Skip this stage with --skip-simulation.
4. Write — writes all output files: Hive-partitioned Parquet for tabular results, JSON manifests, and a FlatBuffers policy checkpoint.

When stdout is a terminal, a progress bar tracks training iterations. A post-run summary is printed to stderr when all stages complete:

Training complete in 12.4s (128 iterations, converged at iter 94)
  Lower bound:  3812.6 $/stage
  Upper bound:  3836.1 +/- 14.2 $/stage
  Gap:          0.6%
  Cuts:         94 active / 94 generated
  LP solves:    4992

Simulation complete (100 scenarios)
  Completed: 100  Failed: 0

Output written to /path/to/my_study/output/

Use --quiet to suppress the banner and progress output in batch scripts, or --verbose to enable debug-level logging when diagnosing solver issues.

Inspect the Results

Use cobre report to get a machine-readable summary of a completed run without loading any Parquet files:

cobre report /path/to/my_study/output

cobre report reads the JSON manifest files written by cobre run and prints a JSON summary to stdout:

{
  "output_directory": "/path/to/my_study/output",
  "status": "complete",
  "training": { "iterations": {}, "convergence": {}, "cuts": {} },
  "simulation": { "scenarios": {} },
  "metadata": { "run_info": {}, "configuration_snapshot": {} }
}

This is suitable for piping to jq for scripted checks:

# Extract the final convergence gap
cobre report /path/to/my_study/output | jq '.training.convergence.final_gap_percent'

# Check whether convergence was achieved
cobre report /path/to/my_study/output | jq '.training.convergence.achieved'

Output file layout

The results directory contains:

output/
  policy/
    cuts/
      stage_000.bin  ...  stage_NNN.bin   # FlatBuffers Benders cuts
    basis/
      stage_000.bin  ...  stage_NNN.bin   # LP warm-start bases
    metadata.json
  training/
    _manifest.json                        # Convergence summary
    convergence.parquet                   # Per-iteration bounds and gap
  simulation/
    _manifest.json                        # Simulation summary
    costs/                                # Stage costs per scenario
    hydros/                               # Hydro dispatch per scenario
    thermals/                             # Thermal dispatch per scenario
    buses/                                # Bus balance per scenario

The key metric to check first is the convergence gap in training/_manifest.json. A gap below 1% is typically very good; 1-5% is acceptable for long-horizon planning; above 5% warrants investigation (consider increasing the iteration limit or forward pass count in config.json).

For a detailed walkthrough of every output file and how to load and analyze the Parquet data in Python or R, see Interpreting Results.

Next Steps

• Configuration — every config.json field: stopping rules, forward pass count, seed, and simulation settings
• Stochastic Modeling — how PAR(p) scenario statistics are structured and what they control
• Interpreting Results — practical analysis patterns for convergence diagnostics and simulation output
• Case Directory Format — complete schema for every input file
• CLI Reference — all flags, subcommands, and exit codes

System Modeling

A Cobre case describes a power system as a collection of entities. Each entity represents a physical component — a bus, a generator, a transmission line — or a contractual obligation. Together, they form the complete model that the solver turns into a sequence of LP sub-problems, one per stage per scenario trajectory.

The fundamental organizing principle is simple: every generator and every load connects to a bus. A bus is an electrical node at which the power balance constraint must hold. At each stage and each load block, the LP enforces that the total power injected into a bus equals the total power withdrawn from it. When the constraint cannot be satisfied by physical generation alone, deficit slack variables absorb the gap at a penalty cost, ensuring the LP always has a feasible solution.

Entities are grouped by type and stored in a System object. The System is built from the case directory by load_case, which runs a five-layer validation pipeline before handing the model to the solver. Within the System, all entity collections are kept in canonical ID-sorted order. This ordering is an invariant: it guarantees that simulation results are bit-for-bit identical regardless of the order entities appear in the input files.

Entity Types

Cobre models seven entity types. Four are fully implemented and contribute LP variables and constraints. Three are registered stubs that appear in the entity model but do not yet contribute LP variables in the current release.

The three stub types are registered in the entity model from Phase 1 so that LP construction code can iterate over all seven types consistently. Adding LP contributions for stub entities is planned for future releases.

How Entities Connect

The network is bus-centric. Every entity that produces or consumes power is attached to a bus via a bus_id field:

   Hydro ──┐
           │ inject
  Thermal ─┤
           ├──> Bus <──── Line ────> Bus
  NCS ─────┘
                │
               load
                │
           Contract
         Pumping Station

At each stage and load block, the LP enforces the bus balance constraint:

  sum(generation at bus) + sum(imports from lines) + deficit
    = load_demand + sum(exports to lines) + excess

Deficit and excess slack variables absorb imbalance at a penalty cost, ensuring the LP is always feasible. When the deficit penalty is high enough relative to the cost of available generation, the solver will prefer to generate rather than incur deficit.

Cascade topology governs hydro plant interactions. A hydro plant with a non-null downstream_id sends all of its outflow — turbined flow plus spillage — into the downstream plant’s reservoir at the same stage. The cascade forms a directed forest: multiple upstream plants may flow into a single downstream plant, but no cycles are allowed. Water balance is computed in topological order — upstream plants first, downstream plants last — in a single pass per stage.

Declaration-Order Invariance

The order in which entities appear in the JSON input files does not affect results. Cobre reads all entities from their files, then sorts each collection by entity ID before building the System. Every function that processes entity collections operates on this canonical sorted order.

This invariant has a practical consequence: you can rearrange entries in buses.json, hydros.json, or any other entity file without changing the simulation output. You can also add new entities with lower IDs than existing ones without disturbing results for the existing entities.

Penalties and Soft Constraints

LP solvers require feasible problems. Physical constraints — minimum outflow, minimum turbined flow, reservoir bounds — can become infeasible under extreme stochastic scenarios (very low inflow, very high load). Cobre handles this by making nearly every physical constraint soft: instead of a hard infeasibility, the solver pays a penalty cost to violate the constraint by a small amount.

Penalties are set at three levels, resolved from most specific to most general:

1. Stage-level override — penalty files for individual stages, when present
2. Entity-level override — a penalties block inside the entity’s JSON object
3. Global default — the top-level penalties.json file in the case directory

This three-tier cascade gives you precise control: you can set a strict global spillage penalty and then relax it for a specific plant that is known to spill frequently in wet years. For details on the penalty fields for each entity type, see the Configuration guide and the Case Format Reference.

The bus deficit segments are the most important penalty to configure correctly. A deficit cost that is too low makes the solver prefer deficit over building generation capacity; a cost that is too high (or an unbounded segment that is absent) can cause numerical instability. The final deficit segment must always have depth_mw: null (unbounded) to guarantee LP feasibility.

Entity Lifecycle

Entities can enter service or be decommissioned at specified stages using entry_stage_id and exit_stage_id fields:

These fields are available on Hydro, Thermal, and Line entities. When a plant has entry_stage_id: 12, the LP does not include any variables for that plant in stages 0 through 11. From stage 12 onward, the plant appears in every sub-problem as normal.

Lifecycle fields are useful for planning studies that span commissioning or retirement events: new thermal plants coming online mid-horizon, or aging hydro units being decommissioned. Each lifecycle event is validated to ensure that entry_stage_id falls within the stage range defined in stages.json.

Related Pages

• Hydro Plants — complete field reference for system/hydros.json
• Thermal Units — complete field reference for system/thermals.json
• Network Topology — buses, lines, deficit modeling, and transmission
• Anatomy of a Case — walkthrough of every file in the 1dtoy example
• Case Format Reference — complete JSON schema for all input files

Hydro Plants

Hydroelectric power plants are the central dispatchable resource in Cobre’s system model. Unlike thermal units, which simply convert fuel into electricity at a cost, hydro plants manage a reservoir — a state variable that persists between stages and couples the dispatch decisions of today to the feasibility of tomorrow. This intertemporal coupling is precisely why hydrothermal scheduling requires stochastic dynamic programming rather than a simple merit-order dispatch.

A hydro plant in Cobre is composed of three physical components: a reservoir that stores water between stages, a turbine that converts water flow into electrical generation, and a spillway that releases excess water without producing power. Each stage’s LP sub-problem contains one water balance constraint per plant: inflow plus beginning storage equals turbined flow plus spillage plus ending storage. The solver decides how much to turbine and how much to store, trading off present-stage generation against future-stage optionality.

Plants can be linked into a cascade via the downstream_id field. When plant A has downstream_id pointing to plant B, all water released from A (turbined flow plus spillage) enters B’s reservoir at the same stage. Cascade topology is validated to be acyclic — no chain of downstream references may loop back to an earlier plant.

For a step-by-step introduction to writing hydros.json, see Building a System and Anatomy of a Case. This page provides the complete field reference with all optional fields documented.

Theory reference: For the mathematical formulation of hydro modeling and the SDDP algorithm that drives dispatch decisions, see SDDP Theory in the methodology reference.

JSON Schema

Hydro plants are defined in system/hydros.json. The top-level object has a single key "hydros" containing an array of plant objects. The following example shows all fields — required and optional — for a single plant:

{
  "hydros": [
    {
      "id": 1,
      "name": "UHE Tucuruí",
      "bus_id": 0,
      "downstream_id": null,
      "entry_stage_id": null,
      "exit_stage_id": null,
      "reservoir": {
        "min_storage_hm3": 50.0,
        "max_storage_hm3": 45000.0
      },
      "outflow": {
        "min_outflow_m3s": 1000.0,
        "max_outflow_m3s": 100000.0
      },
      "generation": {
        "model": "constant_productivity",
        "productivity_mw_per_m3s": 0.8765,
        "min_turbined_m3s": 500.0,
        "max_turbined_m3s": 22500.0,
        "min_generation_mw": 0.0,
        "max_generation_mw": 8370.0
      },
      "tailrace": {
        "type": "polynomial",
        "coefficients": [5.0, 0.001]
      },
      "hydraulic_losses": {
        "type": "factor",
        "value": 0.03
      },
      "efficiency": {
        "type": "constant",
        "value": 0.93
      },
      "evaporation_coefficients_mm": [
        80.0, 75.0, 70.0, 65.0, 60.0, 55.0, 60.0, 65.0, 70.0, 75.0, 80.0, 85.0
      ],
      "diversion": {
        "downstream_id": 2,
        "max_flow_m3s": 200.0
      },
      "filling": {
        "start_stage_id": 48,
        "filling_inflow_m3s": 100.0
      },
      "penalties": {
        "spillage_cost": 0.01,
        "diversion_cost": 0.1,
        "fpha_turbined_cost": 0.05,
        "storage_violation_below_cost": 10000.0,
        "filling_target_violation_cost": 50000.0,
        "turbined_violation_below_cost": 500.0,
        "outflow_violation_below_cost": 500.0,
        "outflow_violation_above_cost": 500.0,
        "generation_violation_below_cost": 1000.0,
        "evaporation_violation_cost": 5000.0,
        "water_withdrawal_violation_cost": 1000.0
      }
    }
  ]
}

The 1dtoy template uses a minimal hydro definition that omits all optional fields. Only id, name, bus_id, downstream_id, reservoir, outflow, and generation are required. All other top-level keys (tailrace, hydraulic_losses, efficiency, evaporation_coefficients_mm, diversion, filling, penalties) are optional and default to off when absent.

Core Fields

These fields appear at the top level of each hydro plant object.

Reservoir

The reservoir block defines the operational storage bounds for the plant. Storage is tracked in hm³ (cubic hectometres; 1 hm³ = 10⁶ m³). The beginning-of-stage storage is the state variable that links consecutive stages in the LP.

"reservoir": {
  "min_storage_hm3": 0.0,
  "max_storage_hm3": 1000.0
}

Setting min_storage_hm3 to the dead volume of your reservoir is important for correctly computing the usable storage range. A reservoir with 500 hm³ total physical capacity but 100 hm³ below the turbine intakes should be modeled as min_storage_hm3: 100.0, max_storage_hm3: 500.0.

Outflow Constraints

The outflow block constrains total outflow from the plant. Total outflow equals turbined flow plus spillage. These constraints are enforced by soft penalties when they cannot be satisfied due to extreme scenario conditions.

"outflow": {
  "min_outflow_m3s": 0.0,
  "max_outflow_m3s": 50.0
}

Minimum outflow is a hard lower bound on the sum of turbined flow and spillage. When the solver cannot meet this bound (for example, because the reservoir is nearly empty and inflow is very low), a violation slack variable is added to the LP at the cost specified by outflow_violation_below_cost in the penalties block.

Generation Models

The generation block configures the turbine model (internally stored as the generation_model field on the Hydro struct). All variants share the core turbine bounds (min_turbined_m3s, max_turbined_m3s) and generation bounds (min_generation_mw, max_generation_mw). The model key selects which production function converts flow to power.

"generation": {
  "model": "constant_productivity",
  "productivity_mw_per_m3s": 1.0,
  "min_turbined_m3s": 0.0,
  "max_turbined_m3s": 50.0,
  "min_generation_mw": 0.0,
  "max_generation_mw": 50.0
}

Available Production Function Models

For the 1dtoy example and for most initial studies, constant_productivity is the correct choice. The productivity_mw_per_m3s factor encodes the plant’s average efficiency and net head. For a plant with 80 m net head and 90% efficiency, the theoretical productivity is approximately 9.81 * 80 * 0.90 / 1000 ≈ 0.706 MW/(m³/s).

Cascade Topology

The downstream_id field creates a directed chain of hydro plants. Water released from an upstream plant — whether turbined or spilled — enters the downstream plant’s reservoir in the same stage.

To model a three-plant cascade where plant 0 flows into plant 1, which flows into plant 2:

{ "id": 0, "downstream_id": 1, ... }
{ "id": 1, "downstream_id": 2, ... }
{ "id": 2, "downstream_id": null, ... }

Cobre validates that the downstream graph is acyclic: no chain of downstream_id references may return to a plant already in the chain. A cycle would make the water balance equation unsolvable. The validator reports the cycle as a topology error with the full chain of plant IDs.

Plants with downstream_id: null are tailwater plants — their outflow leaves the basin. Each connected component of the cascade graph must have exactly one tailwater plant (the chain’s end node). A cascade component with no tailwater plant would be a cycle, which the validator rejects.

Advanced Fields

The following fields enable higher-fidelity physical modeling. They are all optional. For most system planning studies, these fields can be omitted; they become relevant when calibrating a model against historical dispatch data or when the head variation at a plant is significant.

Tailrace Model

The tailrace block models the downstream water level as a function of total outflow. The tailrace elevation affects the net hydraulic head and is used by the linearized_head and fpha generation models. When absent, tailrace elevation is treated as zero.

Two variants are supported:

Polynomial — height = a₀ + a₁·Q + a₂·Q² + …

"tailrace": {
  "type": "polynomial",
  "coefficients": [5.0, 0.001]
}

coefficients is an array of polynomial coefficients in ascending power order. coefficients[0] is the constant term (height at zero outflow in metres), coefficients[1] is the coefficient for Q¹, and so on.

Piecewise — linearly interpolated between (outflow, height) breakpoints.

"tailrace": {
  "type": "piecewise",
  "points": [
    { "outflow_m3s": 0.0, "height_m": 3.0 },
    { "outflow_m3s": 5000.0, "height_m": 4.5 },
    { "outflow_m3s": 15000.0, "height_m": 6.2 }
  ]
}

Points must be sorted in ascending outflow_m3s order. The solver interpolates linearly between adjacent points.

Hydraulic Losses

The hydraulic_losses block models head loss in the penstock and draft tube. Hydraulic losses reduce the effective head available at the turbine. When absent, the penstock is modeled as lossless.

Factor — loss as a fraction of net head:

"hydraulic_losses": { "type": "factor", "value": 0.03 }

value is a dimensionless fraction (e.g., 0.03 = 3% of net head).

Constant — fixed head loss regardless of flow:

"hydraulic_losses": { "type": "constant", "value_m": 2.5 }

value_m is the fixed head loss in metres.

Efficiency Model

The efficiency block scales the power output from the hydraulic power available. When absent, 100% efficiency is assumed.

Currently only the "constant" variant is supported:

"efficiency": { "type": "constant", "value": 0.93 }

value is a dimensionless fraction in the range (0, 1]. A value of 0.93 means the turbine converts 93% of available hydraulic power to electrical output.

Evaporation Coefficients

The evaporation_coefficients_mm field models water loss from the reservoir surface due to evaporation. When present, it must be an array of exactly 12 values, one per calendar month:

"evaporation_coefficients_mm": [
  80.0, 75.0, 70.0, 65.0, 60.0, 55.0,
  60.0, 65.0, 70.0, 75.0, 80.0, 85.0
]

Index 0 is January, index 11 is December. Values are in mm/month. The evaporated volume is computed from the surface area of the reservoir at each stage. When absent, no evaporation is modeled.

Diversion Channel

The diversion block models a water diversion channel that routes flow directly from this plant’s reservoir to a downstream plant’s reservoir, bypassing turbines and spillways. When absent, no diversion is modeled.

"diversion": {
  "downstream_id": 2,
  "max_flow_m3s": 200.0
}

Filling Configuration

The filling block enables a filling operation mode, where the reservoir is intentionally filled from an external, fixed inflow source (such as a diversion works from an unrelated basin) during a defined stage window. When absent, no filling operation is active.

"filling": {
  "start_stage_id": 48,
  "filling_inflow_m3s": 100.0
}

Penalties

The penalties block inside a hydro plant definition overrides the global defaults from penalties.json for that specific plant. When the block is absent, all penalty values fall back to the global defaults. When it is present, it must contain all 11 fields.

Penalty costs are added to the LP objective when soft constraint violations occur. They do not represent physical costs — they are optimization weights that guide the solver to avoid infeasible or undesirable operating states.

"penalties": {
  "spillage_cost": 0.01,
  "diversion_cost": 0.1,
  "fpha_turbined_cost": 0.05,
  "storage_violation_below_cost": 10000.0,
  "filling_target_violation_cost": 50000.0,
  "turbined_violation_below_cost": 500.0,
  "outflow_violation_below_cost": 500.0,
  "outflow_violation_above_cost": 500.0,
  "generation_violation_below_cost": 1000.0,
  "evaporation_violation_cost": 5000.0,
  "water_withdrawal_violation_cost": 1000.0
}

Three-Tier Resolution Cascade

Penalty values are resolved from the most specific to the most general source:

1. Stage-level override (defined in stage-specific penalty files, when present)
2. Entity-level override (the penalties block inside the plant’s JSON object)
3. Global default (the hydro section of penalties.json)

The penalties block on a plant replaces the global default for that plant alone. All plants that do not have a penalties block use the global values from penalties.json. The global penalties.json file must always be present and must contain all 11 hydro penalty fields.

Validation Rules

Cobre’s five-layer validation pipeline checks the following conditions on hydro plants. Violations are reported as error messages with the failing plant’s id and the nature of the problem.

Related Pages

• Anatomy of a Case — walks through the complete 1dtoy hydro definition
• Building a System — step-by-step guide to writing hydros.json from scratch
• System Modeling — overview of all entity types and how they interact
• Case Format Reference — complete JSON schema for all input files

Thermal Units

Thermal power plants are the dispatchable generation assets that complement hydro in Cobre’s system model. The term “thermal” covers any generator whose output is bounded by installed capacity and whose dispatch incurs an explicit cost per MWh: combustion turbines, combined-cycle plants, coal-fired units, nuclear plants, and diesel generators all map onto the same Cobre Thermal entity type.

Unlike hydro plants, thermal units carry no state between stages. Each stage’s LP sub-problem treats a thermal unit as a simple bounded generation variable with a marginal cost. The solver dispatches thermal units in merit order — from cheapest to most expensive — to meet any residual demand not covered by hydro generation. In a hydrothermal system, the long-run value of stored water is compared against the short-run cost of thermal dispatch at each stage, which is the fundamental trade-off the SDDP algorithm optimizes.

The cost structure of a thermal unit is modeled with a piecewise-linear cost curve (cost_segments). A single-segment plant dispatches all its capacity at a flat cost. A multi-segment plant has increasing marginal costs at higher output levels, reflecting the physical reality that a plant becomes less fuel-efficient as it approaches its rated capacity.

For an introductory walkthrough of writing thermals.json, see Building a System and Anatomy of a Case. This page provides the complete field reference, including multi-segment cost curves and GNL configuration.

JSON Schema

Thermal units are defined in system/thermals.json. The top-level object has a single key "thermals" containing an array of unit objects. The following example shows all fields for a two-segment plant with GNL configuration:

{
  "thermals": [
    {
      "id": 0,
      "name": "UTE1",
      "bus_id": 0,
      "cost_segments": [
        {
          "capacity_mw": 15.0,
          "cost_per_mwh": 5.0
        }
      ],
      "generation": {
        "min_mw": 0.0,
        "max_mw": 15.0
      }
    },
    {
      "id": 1,
      "name": "Angra 1",
      "bus_id": 0,
      "entry_stage_id": null,
      "exit_stage_id": null,
      "cost_segments": [
        {
          "capacity_mw": 300.0,
          "cost_per_mwh": 50.0
        },
        {
          "capacity_mw": 357.0,
          "cost_per_mwh": 80.0
        }
      ],
      "generation": {
        "min_mw": 0.0,
        "max_mw": 657.0
      },
      "gnl_config": {
        "lag_stages": 2
      }
    }
  ]
}

The first plant (UTE1) matches the 1dtoy template format: a single cost segment with no optional fields. The second plant (Angra 1) shows the complete schema with a two-segment cost curve and GNL dispatch anticipation. The fields entry_stage_id, exit_stage_id, and gnl_config are optional and can be omitted.

Core Fields

These fields appear at the top level of each thermal unit object.

Generation Bounds

The generation block sets the output limits for the unit (stored internally as min_generation_mw and max_generation_mw on the Thermal struct). These are enforced as hard bounds on the generation variable in each stage LP.

"generation": {
  "min_mw": 0.0,
  "max_mw": 657.0
}

A min_mw of 0.0 means the unit can be turned off completely — it is treated as an interruptible resource. A non-zero min_mw (for example, 100.0 for a plant whose turbine must spin continuously for mechanical reasons) means the LP must always dispatch at least that amount whenever the plant is active.

The max_mw field caps total generation and must equal the sum of all segment capacities in cost_segments. The validator checks this constraint and reports an error if the values do not match.

Cost Segments

The cost_segments array defines the piecewise-linear generation cost curve. Each segment represents a range of generation capacity and its associated marginal cost. Segments are applied in order: the first capacity_mw MW of output uses the first segment’s cost, the next capacity_mw MW uses the second segment’s cost, and so on.

"cost_segments": [
  {
    "capacity_mw": 300.0,
    "cost_per_mwh": 50.0
  },
  {
    "capacity_mw": 357.0,
    "cost_per_mwh": 80.0
  }
]

Single-Segment Plants

Most thermal units in planning studies use a single cost segment, which treats the entire capacity as available at a uniform marginal cost:

"cost_segments": [
  { "capacity_mw": 15.0, "cost_per_mwh": 5.0 }
]

The LP will dispatch this plant at any level between min_mw and max_mw, with the generation cost equal to dispatched_mw * hours_in_block * cost_per_mwh.

Multi-Segment Plants

A multi-segment curve models a plant whose heat rate increases at higher output, which is common for steam turbines and combined-cycle units. For example, a 657 MW plant that is efficient at partial load but increasingly expensive above 300 MW:

"cost_segments": [
  { "capacity_mw": 300.0, "cost_per_mwh": 50.0 },
  { "capacity_mw": 357.0, "cost_per_mwh": 80.0 }
]

The LP sees this as two separate generation variables that are constrained to be dispatched in order: the cheaper 300 MW segment fills first before the solver uses any of the 357 MW higher-cost segment. The total capacity is 300 + 357 = 657 MW, which must equal generation.max_mw.

Segments must be listed in ascending cost order as a convention, though the optimizer will find the merit-order dispatch regardless of the ordering in the file.

Capacity Sum Constraint

The sum of all capacity_mw values must equal generation.max_mw. This is validated by Cobre and reported as a physical feasibility error if violated:

physical error: thermal 1 cost_segments capacity sum (657.0 MW) does not match
  max_generation_mw (700.0 MW)

GNL Configuration

The optional gnl_config block enables GNL (Gás Natural Liquefeito, or liquefied natural gas) dispatch anticipation. This models thermal units that require advance scheduling over multiple stages due to commitment lead times — for example, an LNG-fired plant that must be booked several weeks before the dispatch occurs.

"gnl_config": {
  "lag_stages": 2
}

When lag_stages is greater than zero, the LP structure couples the commitment decision at an earlier stage to the dispatch variable at a later stage. This is an advanced feature for detailed operational planning studies. For most long-term planning horizons where monthly stages are used and commitment detail is not the focus, the gnl_config field can be omitted.

When the gnl_config block is absent, there is no dispatch anticipation lag — the unit can be committed and dispatched independently in each stage’s LP.

Validation Rules

Cobre’s five-layer validation pipeline checks the following conditions on thermal units. Violations are reported as error messages with the failing unit’s id.

Related Pages

• Anatomy of a Case — walks through the complete 1dtoy thermal definitions
• Building a System — step-by-step guide to writing thermals.json from scratch
• System Modeling — overview of all entity types and how they interact
• Case Format Reference — complete JSON schema for all input files

Network Topology

The electrical network in Cobre describes how generators and loads are connected and how power can move between regions. At the heart of the network model is the bus: a named node at which power balance must be maintained every stage and every load block. Generators inject power into buses; loads withdraw power from buses; transmission lines transfer power between buses.

The simplest possible model is a single-bus (copper-plate) system: one bus that aggregates all generation and all load into a single node. In a copper-plate model there are no flow limits, no transmission losses, and no geographical differentiation in price or dispatch. The 1dtoy template uses a single-bus configuration. This is the right starting point for system-level capacity planning studies where the internal transmission network is not the focus.

A multi-bus system introduces two or more buses connected by transmission lines. Lines impose flow limits between buses. When a line’s capacity is binding, each bus has its own locational marginal price, and the dispatch in one region cannot freely substitute for a deficit in another. Multi-bus models are appropriate when regional subsystems have constrained interconnections that influence dispatch, investment decisions, or price formation.

Buses

Every generator and every load must be attached to a bus. Buses are defined in system/buses.json under a top-level "buses" array.

JSON Schema

{
  "buses": [
    {
      "id": 0,
      "name": "SIN",
      "deficit_segments": [
        {
          "depth_mw": null,
          "cost": 1000.0
        }
      ]
    }
  ]
}

This is the complete buses.json from the 1dtoy example: one bus with a single unbounded deficit segment at 1000 $/MWh. The excess_cost field is optional and comes from the global penalties.json when not specified per-bus.

Core Fields

Bus Balance Constraint

For every bus b, every stage t, and every load block k, the LP enforces:

  generation_injected(b, t, k)
  + imports_from_lines(b, t, k)
  + deficit(b, t, k)
  = load_demand(b, t, k)
  + exports_to_lines(b, t, k)
  + excess(b, t, k)

deficit and excess are non-negative slack variables added to the LP objective at their respective penalty costs. The deficit slack makes the problem feasible when there is not enough generation to meet demand. The excess slack absorbs surplus generation when more power is produced than can be consumed or transmitted away.

Deficit Modeling

Deficit represents unserved load — demand that the solver cannot cover with available generation. The deficit cost is the Value of Lost Load (VoLL) from the solver’s perspective: the penalty the LP pays per MWh of unserved demand.

Deficit Segments

Rather than a single flat VoLL, Cobre models deficit costs as a piecewise-linear curve: a sequence of segments with increasing costs. The segments are cumulative. The first segment covers the first depth_mw MW of deficit at the lowest cost, the second segment covers the next depth_mw MW at a higher cost, and so on.

"deficit_segments": [
  { "depth_mw": 500.0, "cost": 1000.0 },
  { "depth_mw": null,  "cost": 5000.0 }
]

In this two-segment example, the first 500 MW of deficit costs 1000 $/MWh. Any deficit above 500 MW costs 5000 $/MWh. The final segment must have depth_mw: null (unbounded), which guarantees the LP can always find a feasible solution regardless of the generation shortfall.

Three-Tier Penalty Resolution

Deficit segment values are resolved from the most specific to the most general source:

1. Stage-level override — penalty files for individual stages, when present
2. Bus-level override — the deficit_segments array inside the bus’s JSON object
3. Global default — the bus.deficit_segments section of penalties.json

When deficit_segments is omitted from a bus definition, Cobre uses the global default from penalties.json. This makes it easy to set a system-wide VoLL and then override it for specific buses with different reliability requirements.

Choosing Deficit Costs

A typical two-tier configuration uses a moderate cost for the first tier (to allow partial deficit in extreme scenarios without distorting the optimality cuts too much) and a very high cost for the unbounded final tier (to make full deficit a last resort). Values of 1000–5000 $/MWh for the first tier and 5000–20000 $/MWh for the final tier are common in practice.

Setting the deficit cost too low relative to thermal generation costs will cause the solver to prefer deficit over building reserves, which misrepresents the cost of unserved energy. Setting it too high can cause numerical conditioning issues in the LP; in practice, values above 100 000 $/MWh are rarely necessary.

Lines

Transmission lines connect pairs of buses and impose flow limits on power transfer between them. Lines are defined in system/lines.json under a top-level "lines" array. A single-bus system has an empty lines array.

JSON Schema

The following example shows a two-bus system with a single connecting line:

{
  "lines": [
    {
      "id": 0,
      "name": "North-South Interconnection",
      "source_bus_id": 0,
      "target_bus_id": 1,
      "entry_stage_id": null,
      "exit_stage_id": null,
      "direct_capacity_mw": 1000.0,
      "reverse_capacity_mw": 800.0,
      "losses_percent": 2.5,
      "exchange_cost": 1.0
    }
  ]
}

This line allows up to 1000 MW to flow from bus 0 to bus 1, and up to 800 MW in the reverse direction. A 2.5% transmission loss is applied to all flow. The exchange_cost is a regularization penalty, not a physical cost.

Core Fields

Exchange Cost Note

The exchange_cost is not a tariff or a physical transmission cost — it is a regularization penalty added to the LP objective to give the solver a strict preference between equivalent dispatch solutions. Without any exchange cost, the solver is indifferent between using or not using a lossless, uncongested line, which can cause oscillations between equivalent solutions across iterations.

A small exchange cost (0.5–2.0 $/MWh) breaks this degeneracy without meaningfully distorting the economic dispatch. The global default is set in penalties.json under line.exchange_cost. Per-line overrides are not currently supported; the global value applies to all lines.

Transmission Losses

When losses_percent is non-zero, the power arriving at the target bus is less than the power leaving the source bus. If bus A sends F MW to bus B over a line with 2.5% losses, then:

• Bus A’s balance sees an outflow of F MW
• Bus B’s balance sees an inflow of F * (1 - 0.025) = 0.975 * F MW

The lost power (0.025 * F MW) does not appear anywhere in the network — it represents heat dissipated in the conductor. From the LP’s perspective, losses increase the effective cost of transferring power: the source bus must generate more to deliver the same amount at the target bus.

Setting losses_percent: 0.0 models a lossless (superconductive) connection. This is appropriate for short, high-voltage DC links or for cases where transmission losses are not a modeling concern.

Single-Bus vs Multi-Bus

When to use a single-bus model

A single bus (copper-plate) is appropriate when:

• You are building an initial case and want to isolate dispatch economics from network effects
• Transmission constraints are not binding in the scenarios you are studying
• The system is geographically compact with ample interconnection capacity
• You are validating the stochastic model before adding network complexity

The 1dtoy template is a single-bus case. All generators and loads connect to bus 0 (SIN), and lines.json contains an empty array.

When to use a multi-bus model

A multi-bus model is appropriate when:

• Different regions have distinct generation mixes and load profiles
• Transmission capacity is a binding constraint that affects dispatch or pricing
• You need locational marginal prices for investment decisions or contract pricing
• You are modeling a system where curtailment of cheap generation (wind in one region, hydro in another) is caused by transmission congestion

Adding a second bus

To extend the 1dtoy template to two buses, add a second bus to buses.json:

{
  "buses": [
    { "id": 0, "name": "North" },
    { "id": 1, "name": "South" }
  ]
}

Then add a line to lines.json:

{
  "lines": [
    {
      "id": 0,
      "name": "North-South",
      "source_bus_id": 0,
      "target_bus_id": 1,
      "direct_capacity_mw": 500.0,
      "reverse_capacity_mw": 500.0,
      "losses_percent": 1.0,
      "exchange_cost": 1.0
    }
  ]
}

Assign each generator and load to the appropriate bus by setting its bus_id. When you run cobre validate, the validator will confirm that all bus_id references resolve to existing buses.

Validation Rules

Cobre’s five-layer validation pipeline checks the following conditions for buses and lines. Violations are reported as error messages with the failing entity’s id.

When a bus ID referenced by a generator does not exist in buses.json, the validator reports the error as:

reference error: thermal 2 references bus 99 which does not exist

Fix the bus_id or add the missing bus and re-run cobre validate until the exit code is 0.

Related Pages

• System Modeling — overview of all entity types and how they compose the LP
• Anatomy of a Case — walkthrough of the complete 1dtoy case including buses.json and lines.json
• Building a System — step-by-step guide to creating buses and lines from scratch
• Case Format Reference — complete JSON schema for all input files

Stochastic Modeling

Hydrothermal dispatch is inherently uncertain. Reservoir inflows depend on rainfall and snowmelt that cannot be known in advance, and electrical load varies in ways that are predictable in aggregate but noisy at any given moment. A dispatch policy that ignores uncertainty will systematically under-prepare for dry periods and over-commit thermal capacity in wet years.

Cobre addresses this by treating inflows and loads as stochastic processes. During training, the solver samples many scenario trajectories and builds a policy that performs well across the distribution of possible futures — not just for a single forecast. The stochastic layer is responsible for generating those scenario trajectories in a statistically sound, reproducible way.

The stochastic models are driven by historical statistics provided by the user in the scenarios/ directory of the case. If no scenarios/ directory is present, Cobre falls back to white-noise generation using only the stage definitions in stages.json. For any study with real hydro plants, providing historical inflow statistics is strongly recommended.

The scenarios/ Directory

The scenarios/ directory sits alongside the other input files in the case directory:

my_study/
  config.json
  stages.json
  ...
  scenarios/
    inflow_seasonal_stats.parquet
    load_seasonal_stats.parquet
    inflow_ar_coefficients.parquet    (only when ar_order > 0)

The directory is optional. When it is absent, Cobre generates independent standard-normal noise at each stage for each hydro plant and scales it by a default standard deviation — effectively treating all uncertainty as white noise. This is sufficient for verifying a case loads correctly, but is not representative of real inflow dynamics.

When scenarios/ is present, Cobre reads the Parquet files and fits a Periodic Autoregressive (PAR(p)) model for each hydro plant and each bus. The fitted model generates correlated, seasonally-varying inflow and load trajectories that reflect the historical statistics you supply.

Inflow Statistics

inflow_seasonal_stats.parquet provides the seasonal distribution of historical inflows for every (hydro plant, stage) pair.

Schema

The file must contain exactly one row per (hydro_id, stage_id) pair. Every hydro plant defined in hydros.json must have a row for every stage defined in stages.json. The validator will reject the case if any combination is missing.

For the 1dtoy example, the file has 4 rows — one for each of the four monthly stages — for the single hydro plant UHE1 (hydro_id = 0).

Inspecting the file

# Polars
import polars as pl
df = pl.read_parquet("scenarios/inflow_seasonal_stats.parquet")
print(df)

# Pandas
import pandas as pd
df = pd.read_parquet("scenarios/inflow_seasonal_stats.parquet")
print(df)

-- DuckDB
SELECT * FROM read_parquet('scenarios/inflow_seasonal_stats.parquet');

# R with arrow
library(arrow)
df <- read_parquet("scenarios/inflow_seasonal_stats.parquet")
print(df)

Load Statistics

load_seasonal_stats.parquet provides the seasonal distribution of electrical demand at each bus. It drives the stochastic load model used during training and simulation.

Schema

One row per (bus_id, stage_id) pair is required. Every bus in buses.json must have a row for every stage. The load mean and standard deviation determine both the expected demand level and how much it varies across scenarios in each stage.

The PAR(p) Model

PAR(p) stands for Periodic Autoregressive model of order p. It is the standard model for hydro inflow time series in long-term hydrothermal planning because inflows have two key properties the model captures well: seasonal patterns (wet seasons and dry seasons recur predictably each year) and autocorrelation (a wet month tends to be followed by another wet month, and vice versa).

What ar_order controls

The ar_order column in the seasonal statistics files sets the number of autoregressive lags for each (entity, stage) pair.

ar_order = 0 — white noise. The inflow at each stage is drawn independently from a normal distribution with the specified mean and standard deviation. There is no memory between stages: knowing last month’s inflow tells you nothing about this month’s. This is the simplest setting and appropriate when you lack historical data to fit AR coefficients, or when the inflow series shows very little autocorrelation.

ar_order > 0 — periodic autoregressive. The inflow at each stage depends on the inflows at the preceding p stages, weighted by coefficients that reflect the seasonal autocorrelation structure. A wet period is followed by another wet period with the probability implied by the coefficients. Higher AR orders capture longer-range dependencies: ar_order = 1 captures month-to-month persistence, ar_order = 2 adds two-month memory, and so on. Most hydro inflow series are well-described by ar_order = 1 or ar_order = 2.

AR coefficients file

When any stage in inflow_seasonal_stats.parquet has ar_order > 0, Cobre also requires an inflow_ar_coefficients.parquet file in the scenarios/ directory. This file contains the fitted AR coefficients in standardized form (as produced by the Yule-Walker equations). The schema and the fitting procedure are documented in the Case Format Reference.

The 1dtoy example uses ar_order = 0 for all stages, so no coefficients file is needed.

When to use higher AR orders

In general:

• Use ar_order = 0 when historical data is short or when you want to establish a baseline with the simplest possible model.
• Use ar_order = 1 for most real hydro systems. Monthly inflows have strong one-month autocorrelation, and a first-order model captures the bulk of it.
• Use ar_order = 2 or higher when the inflow series shows multi-month persistence (common in systems with large upstream catchments or snowmelt storage). Validate with autocorrelation plots of your historical data.
• Setting ar_order > 0 with std_m3s = 0 is a validation error — the model requires non-zero variance to be identifiable.

For the theoretical derivation of the PAR(p) model, see Stochastic Modeling and PAR(p) Autoregressive Models in the methodology reference.

Correlation

Hydro plants that share a watershed tend to have correlated inflows: when the upstream basin receives heavy rainfall, all plants along the river benefit simultaneously. Ignoring this correlation can cause the optimizer to underestimate the risk of a system-wide dry spell.

Default behavior: independent noise

When no correlation configuration is provided, Cobre treats each hydro plant’s inflow as independent of all others. Each plant draws its own noise realization at each stage without any coupling. This is the correct setting for the 1dtoy example, which has only one hydro plant.

Configuring spatial correlation

For multi-plant systems, Cobre supports Cholesky-based spatial correlation. A correlation model is specified in correlation.json in the case directory and defines named correlation groups, each with a symmetric positive-definite correlation matrix.

{
  "method": "cholesky",
  "profiles": {
    "default": {
      "groups": [
        {
          "name": "basin_south",
          "entities": [
            { "type": "inflow", "id": 0 },
            { "type": "inflow", "id": 1 }
          ],
          "matrix": [
            [1.0, 0.7],
            [0.7, 1.0]
          ]
        }
      ]
    }
  }
}

Entities not listed in any group retain independent noise. Multiple profiles can be defined and scheduled to activate for specific stages (for example, using a wet-season correlation structure in January through March and a dry-season structure for the remaining months). Detailed correlation configuration documentation will be added with future multi-plant example cases.

Scenario Count and Seeds

num_scenarios in stages.json

Each stage in stages.json has a num_scenarios field that controls how many scenario branches are pre-generated for the opening scenario tree used during the backward pass. A larger value gives the backward pass more diverse inflow realizations to evaluate cuts against, at the cost of a proportionally larger opening tree in memory. For the 1dtoy example this is set to 10. Production studies typically use 50 to 200.

forward_passes in config.json

The forward_passes field in config.json controls how many scenario trajectories are sampled during each training iteration’s forward pass. This is distinct from num_scenarios: the forward pass draws new trajectories on each iteration using a deterministic per-iteration seed, while num_scenarios controls the pre-generated backward-pass tree.

The seed field

The seed field in the training section of config.json is the base seed for all stochastic generation in the run:

{
  "training": {
    "forward_passes": 50,
    "seed": 42,
    "stopping_rules": [{ "type": "iteration_limit", "limit": 200 }]
  }
}

The default value is 42 when seed is omitted. When a seed is provided, every run with the same case directory and the same seed produces bitwise-identical scenarios, training trajectories, and simulation results. This reproducibility is guaranteed regardless of the number of MPI ranks, because each rank derives its scenario seeds independently from the base seed using a deterministic hash — no inter-rank coordination is required.

To get a non-reproducible run (different scenarios each time), set "seed": null in config.json. Cobre will then derive the base seed from OS entropy at startup.

Inflow Non-Negativity

Normal distributions used in PAR(p) models have unbounded support: even with a positive mean, there is a non-zero probability of drawing a negative noise realisation that, after applying the AR dynamics, produces a negative inflow value. Negative inflow has no physical meaning and, if uncorrected, would violate water balance constraints in the LP.

Method in v0.1.0: penalty

Cobre v0.1.0 uses the penalty method to handle negative inflow realisations. A high-cost slack variable is added to each water balance row. When the LP solver encounters a scenario where the inflow would be negative, it draws on this virtual inflow at the penalty cost rather than violating the balance constraint. The penalty cost is configurable via the inflow_non_negativity field in the case configuration; the default keeps it high enough that the slack is used only when necessary.

In practice, the penalty is rarely activated in well-specified studies. It acts as a backstop for low-probability tail realisations.

Truncation methods: planned for a future release

Two additional methods from the literature — truncation (modifying LP row bounds based on external AR evaluation) and truncation with penalty (combining bounded slack with modified bounds) — are planned for a future release. These require evaluating the full inflow value a_h as a scalar before LP patching, which is a non-trivial architectural change in v0.1.0.

For the mathematical theory behind all three methods, see the Inflow Non-Negativity page in the methodology reference, or Oliveira et al. (2022), Energies 15(3):1115.

Related Pages

• Anatomy of a Case — introductory walkthrough of the scenarios/ directory and Parquet schemas
• Configuration — full documentation of config.json fields including seed and forward_passes
• cobre-stochastic — internal architecture of the stochastic crate: PAR preprocessing, Cholesky correlation, opening tree, and seed derivation

Running Studies

End-to-end workflow for running an SDDP study with cobre run, interpreting output, and inspecting results.

Preparing a Case Directory

A case directory is a folder containing all input data files required by Cobre. The minimum required structure is:

my_study/
  config.json
  penalties.json
  stages.json
  initial_conditions.json
  system/
    buses.json
    hydros.json
    thermals.json
    lines.json

All eight files are required. Before running, validate the input:

cobre validate /path/to/my_study

Successful validation prints entity counts and exits with code 0. Fix any reported errors before proceeding. See Case Directory Format for the full schema.

Running cobre run

cobre run /path/to/my_study

By default, results are written to <CASE_DIR>/output/. To specify a different location:

cobre run /path/to/my_study --output /path/to/results

Lifecycle Stages

1. Load — reads input files, runs 5-layer validation (exits code 1 on validation failure, 2 on I/O error)
2. Train — builds the SDDP policy by iterating forward/backward passes; stops when stopping rules are met
3. Simulate — (optional) evaluates the policy over independent scenarios; requires simulation.enabled = true
4. Write — writes Hive-partitioned Parquet (tabular), JSON manifests/metadata, and FlatBuffers output

Terminal Output

Banner

When stdout is a terminal, a banner shows the version and solver backend. Suppress with --no-banner (keeps progress bars) or --quiet (suppresses all except errors).

Progress Bars

During training, a progress bar shows current iteration count. In --quiet mode, no progress bars are printed. Errors are always written to stderr.

Summary

After all stages complete, a run summary is printed to stderr with:

• Training: iteration count, convergence status, bounds, gap, cuts, solves, time
• Simulation (when enabled): scenarios requested, completed, failed
• Output directory: absolute path to results

Checking Results

Use cobre report to inspect the results:

cobre report /path/to/my_study/output

Reads manifest files and prints JSON to stdout (suitable for piping to jq):

cobre report /path/to/my_study/output | jq '.training.convergence.final_gap_percent'

Exits with code 0 on success or 2 if the results directory does not exist.

Common Workflows

Training Only

cobre run /path/to/my_study --skip-simulation

Trains the policy without simulation.

Quiet Mode for Scripts

cobre run /path/to/my_study --quiet
exit_code=$?
if [ $exit_code -ne 0 ]; then
  echo "Study failed with exit code $exit_code" >&2
fi

Suppresses banner and progress output, suitable for batch scripts.

Checking Exit Codes

See CLI Reference for the full exit code table.

Configuration

All runtime parameters for cobre run are controlled by config.json in the case directory. This page documents every section and field.

Minimal Config

{
  "version": "2.0.0",
  "training": {
    "forward_passes": 50,
    "stopping_rules": [{ "type": "iteration_limit", "limit": 100 }]
  }
}

All other sections are optional with defaults documented below.

training

Controls the SDDP training phase.

Mandatory Fields

Optional Fields

Stopping Rules

Each entry in stopping_rules is a JSON object with a "type" discriminator.

iteration_limit

Stop after a fixed number of training iterations.

{ "type": "iteration_limit", "limit": 200 }

time_limit

Stop after a wall-clock time budget is exhausted.

{ "type": "time_limit", "seconds": 3600.0 }

bound_stalling

Stop when the relative improvement in the lower bound falls below a threshold.

{ "type": "bound_stalling", "iterations": 20, "tolerance": 0.0001 }

stopping_mode

When multiple stopping rules are listed, stopping_mode controls how they combine:

• "any" (default): stop when any one rule is satisfied.
• "all": stop only when every rule is satisfied simultaneously.

{
  "training": {
    "forward_passes": 50,
    "stopping_mode": "all",
    "stopping_rules": [
      { "type": "iteration_limit", "limit": 500 },
      { "type": "bound_stalling", "iterations": 20, "tolerance": 0.0001 }
    ]
  }
}

simulation

Controls the optional post-training simulation phase.

When simulation.enabled is false or num_scenarios is 0, the simulation phase is skipped regardless of the --skip-simulation flag.

Example:

{
  "simulation": {
    "enabled": true,
    "num_scenarios": 1000
  }
}

policy

Controls policy persistence (checkpoint saving and warm-start loading).

exports

Controls which outputs are written to the results directory.

Full Example

{
  "$schema": "https://cobre.dev/schemas/v2/config.schema.json",
  "version": "2.0.0",
  "training": {
    "seed": 42,
    "forward_passes": 50,
    "stopping_rules": [
      { "type": "iteration_limit", "limit": 200 },
      { "type": "bound_stalling", "iterations": 20, "tolerance": 0.0001 }
    ],
    "stopping_mode": "any"
  },
  "simulation": {
    "enabled": true,
    "num_scenarios": 2000
  },
  "policy": {
    "path": "./policy",
    "mode": "fresh"
  },
  "exports": {
    "training": true,
    "cuts": true,
    "states": true,
    "simulation": true,
    "compression": "zstd"
  }
}

See Also

• Case Directory Format — full schema for all input files
• Running Studies — end-to-end workflow guide
• Error Codes — validation errors including SchemaError for config fields

CLI Reference

Synopsis

cobre [--color <WHEN>] <SUBCOMMAND> [OPTIONS]

Global Options

Subcommands

cobre run

Executes the full solve lifecycle for a case directory:

1. Load — reads all input files and runs the 5-layer validation pipeline
2. Train — trains an SDDP policy using the configured stopping rules
3. Simulate — (optional) evaluates the trained policy over simulation scenarios
4. Write — writes all output files to the results directory

Arguments

Options

Examples

# Run a study with default output location
cobre run /data/cases/hydro_study

# Write results to a custom directory
cobre run /data/cases/hydro_study --output /data/results/run_001

# Train only, no simulation
cobre run /data/cases/hydro_study --skip-simulation

# Use 4 worker threads per MPI rank
cobre run /data/cases/hydro_study --threads 4

# Run without any terminal decorations (useful in scripts)
cobre run /data/cases/hydro_study --quiet

# Force color output when running under mpiexec
cobre --color always run /data/cases/hydro_study

# Enable verbose logging to diagnose solver issues
cobre run /data/cases/hydro_study --verbose

cobre validate

Runs the 5-layer validation pipeline and prints a diagnostic report to stdout.

On success, prints entity counts:

Valid case: 3 buses, 12 hydros, 8 thermals, 4 lines
  buses: 3
  hydros: 12
  thermals: 8
  lines: 4

On failure, prints each error prefixed with error: and exits with code 1:

Arguments

Options

None.

Examples

# Validate a case directory before running
cobre validate /data/cases/hydro_study

# Use in a script: only proceed if validation passes
cobre validate /data/cases/hydro_study && cobre run /data/cases/hydro_study

cobre report

Reads the JSON manifests written by cobre run and prints a JSON summary to stdout.

The output has the following top-level shape:

{
  "output_directory": "/abs/path/to/results",
  "status": "complete",
  "training": { "iterations": {}, "convergence": {}, "cuts": {} },
  "simulation": { "scenarios": {} },
  "metadata": { "run_info": {}, "configuration_snapshot": {} }
}

simulation and metadata are null when the corresponding files are absent (e.g., when --skip-simulation was used).

Arguments

Options

None.

Examples

# Print the full report to the terminal
cobre report /data/cases/hydro_study/output

# Extract the convergence gap using jq
cobre report /data/cases/hydro_study/output | jq '.training.convergence.final_gap_percent'

# Check the run status in a script
status=$(cobre report /data/cases/hydro_study/output | jq -r '.status')
if [ "$status" = "complete" ]; then
  echo "Training converged"
fi

cobre version

Prints the binary version, active solver and communication backends, compression support, host architecture, and build profile.

Output Format

cobre   v0.1.0
solver: HiGHS
comm:   local
zstd:   enabled
arch:   x86_64-linux
build:  release (lto=thin)

Arguments

None.

Options

None.

Exit Codes

All subcommands follow the same exit code convention.

Codes 1–2 indicate user-correctable input problems; codes 3–4 indicate case/environment problems. Error messages are printed to stderr with error: prefix and hint lines. See Error Codes for a detailed catalog.

Environment Variables

Interpreting Results

The Understanding Results tutorial explains what each output file contains and how to read it. This page goes one level deeper: it provides practical analysis patterns for answering domain questions from the data. It assumes you have already completed the tutorial and are comfortable loading Parquet files in your preferred tool.

The focus is on convergence diagnostics and simulation analysis. By the end of this page you will know how to assess whether a run converged, how to extract generation and cost statistics across scenarios, and how to identify common problems from the output data.

Convergence Diagnostics

Reading the gap from training/_manifest.json

The manifest is the first place to check after any run. The key fields for convergence assessment are:

{
  "convergence": {
    "achieved": false,
    "final_gap_percent": 0.6,
    "termination_reason": "iteration_limit"
  },
  "iterations": {
    "completed": 128,
    "converged_at": null
  }
}

Gap guidelines. There is no universal threshold — acceptable gap depends on the decision being made and the study’s time horizon. As rough guidance:

• Below 1%: typically very good. The policy cost is within 1% of the theoretical optimum.
• 1% to 5%: acceptable for long-horizon planning studies where model uncertainty is already large.
• Above 5%: warrants investigation. The policy may be significantly suboptimal.

What to do if the gap is large:

1. Increase limit in the iteration_limit stopping rule.
2. Increase forward_passes in config.json to reduce noise in the upper bound estimate per iteration.
3. Check training/convergence.parquet (see next section) to see whether the gap is still decreasing or has plateaued.
4. Check for solver infeasibilities: if simulation/_manifest.json shows failed scenarios, the policy may be encountering numerically difficult stages.

Reading Convergence History

training/convergence.parquet contains one row per training iteration with the full convergence history. Its schema:

Python (Polars)

import polars as pl
import matplotlib.pyplot as plt

df = pl.read_parquet("results/training/convergence.parquet")

# Plot convergence bounds over iterations
plt.figure(figsize=(10, 4))
plt.plot(df["iteration"], df["lower_bound"], label="Lower bound")
plt.plot(df["iteration"], df["upper_bound_mean"], label="Upper bound (mean)")
plt.fill_between(
    df["iteration"].to_list(),
    (df["upper_bound_mean"] - df["upper_bound_std"]).to_list(),
    (df["upper_bound_mean"] + df["upper_bound_std"]).to_list(),
    alpha=0.2,
    label="Upper bound ± 1 std",
)
plt.xlabel("Iteration")
plt.ylabel("Expected cost ($/stage)")
plt.legend()
plt.tight_layout()
plt.show()

# Check final gap
final = df.filter(pl.col("iteration") == df["iteration"].max())
print(final.select(["iteration", "lower_bound", "upper_bound_mean", "gap_percent"]))

R

library(arrow)
library(ggplot2)

df <- read_parquet("results/training/convergence.parquet")

# Plot convergence bounds
ggplot(df, aes(x = iteration)) +
  geom_line(aes(y = lower_bound, color = "Lower bound")) +
  geom_line(aes(y = upper_bound_mean, color = "Upper bound")) +
  geom_ribbon(
    aes(
      ymin = upper_bound_mean - upper_bound_std,
      ymax = upper_bound_mean + upper_bound_std
    ),
    alpha = 0.2
  ) +
  labs(
    x = "Iteration",
    y = "Expected cost ($/stage)",
    color = NULL
  ) +
  theme_minimal()

# Print final gap
tail(df[, c("iteration", "lower_bound", "upper_bound_mean", "gap_percent")], 1)

What to look for in the convergence plot:

• Both bounds should move toward each other over iterations. The lower bound rises; the upper bound mean falls and its standard deviation narrows.
• A lower bound that stays flat after the first few iterations suggests the backward pass cuts are not improving: check cuts_added to confirm cuts are being generated.
• An upper bound that oscillates widely without narrowing suggests the forward_passes count is too low to produce a stable estimate.

Analyzing Simulation Results

The simulation output is Hive-partitioned: results are stored in one data.parquet file per scenario under simulation/<category>/scenario_id=NNNN/. Polars, Pandas, R arrow, and DuckDB all support reading the entire directory as a single table and filtering by scenario_id at the storage layer.

Aggregating across scenarios

The most common operation is computing statistics across all scenarios for a given entity or stage.

Python (Polars) — mean and percentiles:

import polars as pl

# Load all hydro results across all scenarios
hydros = pl.read_parquet("results/simulation/hydros/")

# Mean generation per hydro plant per stage, across all scenarios
mean_gen = (
    hydros
    .group_by(["hydro_id", "stage_id"])
    .agg(
        pl.col("generation_mwh").mean().alias("mean_generation_mwh"),
        pl.col("generation_mwh").quantile(0.10).alias("p10_generation_mwh"),
        pl.col("generation_mwh").quantile(0.90).alias("p90_generation_mwh"),
    )
    .sort(["hydro_id", "stage_id"])
)
print(mean_gen)

R:

library(arrow)
library(dplyr)

# Load all hydro results
hydros <- open_dataset("results/simulation/hydros/") |> collect()

# Mean and P10/P90 generation per hydro plant per stage
mean_gen <- hydros |>
  group_by(hydro_id, stage_id) |>
  summarise(
    mean_generation_mwh = mean(generation_mwh),
    p10_generation_mwh  = quantile(generation_mwh, 0.10),
    p90_generation_mwh  = quantile(generation_mwh, 0.90),
    .groups = "drop"
  ) |>
  arrange(hydro_id, stage_id)

print(mean_gen)

Filtering to a single scenario

# Polars — read only scenario 0 (avoids loading all partitions)
costs_s0 = pl.read_parquet(
    "results/simulation/costs/",
    hive_partitioning=True,
).filter(pl.col("scenario_id") == 0)

-- DuckDB
SELECT * FROM read_parquet('results/simulation/costs/**/*.parquet')
WHERE scenario_id = 0
ORDER BY stage_id;

Common Analysis Tasks

(a) Expected generation by hydro plant

import polars as pl

hydros = pl.read_parquet("results/simulation/hydros/")
expected = (
    hydros
    .group_by("hydro_id")
    .agg(pl.col("generation_mwh").mean().alias("mean_annual_generation_mwh"))
    .sort("hydro_id")
)
print(expected)

(b) Expected thermal generation cost

thermals = pl.read_parquet("results/simulation/thermals/")
thermal_cost = (
    thermals
    .group_by("thermal_id")
    .agg(pl.col("generation_cost").mean().alias("mean_total_cost"))
    .sort("thermal_id")
)
print(thermal_cost)

In R:

library(arrow)
library(dplyr)

thermals <- open_dataset("results/simulation/thermals/") |> collect()

thermal_cost <- thermals |>
  group_by(thermal_id) |>
  summarise(mean_total_cost = mean(generation_cost), .groups = "drop") |>
  arrange(thermal_id)

print(thermal_cost)

(c) Deficit probability per bus

A scenario has a deficit at a given stage if deficit_mwh > 0 for any bus in that stage. The deficit probability is the fraction of scenarios where this occurs.

buses = pl.read_parquet("results/simulation/buses/")
n_scenarios = buses["scenario_id"].n_unique()

deficit_prob = (
    buses
    .group_by(["bus_id", "stage_id"])
    .agg(
        (pl.col("deficit_mwh") > 0).mean().alias("deficit_probability")
    )
    .sort(["bus_id", "stage_id"])
)
print(deficit_prob)

(d) Water value (shadow price) from hydro output

The water_value_per_hm3 column in simulation/hydros/ records the shadow price of reservoir storage at each stage — the marginal value of having one additional hm³ of stored water. This is the water value, a key output of the SDDP policy.

hydros = pl.read_parquet("results/simulation/hydros/")
water_value = (
    hydros
    .group_by(["hydro_id", "stage_id"])
    .agg(pl.col("water_value_per_hm3").mean().alias("mean_water_value"))
    .sort(["hydro_id", "stage_id"])
)
print(water_value)

A high water value at a given stage means the reservoir is scarce relative to expected future demand — the solver is conserving water for later stages. A water value near zero means the reservoir is abundant and water has little marginal value at that point in time.

Using cobre report

cobre report provides a quick machine-readable summary without loading any Parquet files:

cobre report results/

Use it in scripts or CI pipelines to extract a specific metric without writing a data loading script:

# Check the final gap in a CI pipeline
gap=$(cobre report results/ | jq '.training.convergence.final_gap_percent')
echo "Final gap: ${gap}%"

For all available cobre report fields and flags, see CLI Reference.

Troubleshooting

Gap not converging

The gap stays large after many iterations, or the lower bound rises very slowly.

Possible causes:

• Too few iterations. The most common cause. Increase the iteration_limit.
• Too few forward passes. A forward_passes count of 1 (as in the 1dtoy tutorial) gives high variance in the upper bound estimate. Increase to 10 or more for a stable gap reading.
• Numerically difficult stages. Check training/convergence.parquet for iterations where cuts_added is zero — this can indicate stages where the backward pass is not generating improving cuts.
• Policy horizon issues. Verify stages.json has the correct stage ordering and that policy_graph.type is set correctly.

Unexpected deficit

Simulation scenarios show non-zero deficit_mwh in simulation/buses/ but the system should have enough capacity.

Possible causes:

• Insufficient thermal capacity. Compare total load (load_mw summed across buses) against total thermal capacity. If load exceeds generation capacity in some scenarios, deficit is unavoidable.
• Hydro reservoir ran dry. Check storage_final_hm3 in simulation/hydros/. If it hits zero in early stages, subsequent stages have no hydro generation and may resort to deficit.
• Very low deficit penalty. If deficit_segments in penalties.json are priced below thermal generation cost, the solver will prefer deficit over generation. Increase the deficit cost.

Zero generation from a plant

A thermal or hydro plant shows zero generation in all scenarios.

Possible causes:

• Plant is more expensive than deficit. Check the plant’s cost against the bus deficit penalty. If the cost exceeds the penalty, deficit is cheaper and the solver avoids dispatching the plant.
• Bus connectivity. Verify the plant’s bus_id matches a bus that actually has load. A plant connected to a zero-load bus will never be dispatched.
• Hydro: reservoir constraints too tight. If min_storage_hm3 is close to the initial storage level, the solver cannot turbine water without risking a storage violation. Review initial_conditions.json and storage bounds in hydros.json.

Related Pages

• Understanding Results — file-by-file walkthrough of every output artifact
• Output Format Reference — complete field-by-field schema for all output files
• Configuration — all config.json fields including stopping rules and seed

Crate Overview

Cobre is organized as a Rust workspace with 11 crates. Each crate has a single responsibility and well-defined boundaries.

cobre/crates/
├── cobre-core/         Entity model (buses, hydros, thermals, lines)
├── cobre-io/           JSON/Parquet input, FlatBuffers/Parquet output
├── cobre-stochastic/   PAR(p) models, scenario generation
├── cobre-solver/       LP solver abstraction (HiGHS backend)
├── cobre-comm/         Communication abstraction (MPI, TCP, shm, local)
├── cobre-sddp/         SDDP training loop, simulation, cut management
├── cobre-cli/          Binary: run/validate/report/compare/serve
├── cobre-mcp/          Binary: MCP server for AI agent integration
├── cobre-python/       cdylib: PyO3 Python bindings
└── cobre-tui/          Library: ratatui terminal UI

Dependency Graph

The diagram below shows the primary dependency relationships between workspace crates. Arrows point from dependency to dependent (i.e., an arrow from cobre-core to cobre-io means cobre-io depends on cobre-core).

graph TD
    core[cobre-core]
    io[cobre-io]
    solver[cobre-solver]
    comm[cobre-comm]
    stochastic[cobre-stochastic]
    sddp[cobre-sddp]
    cli[cobre-cli]
    ferrompi[ferrompi]

    core --> io
    core --> stochastic
    core --> solver
    core --> comm
    ferrompi --> comm
    io --> sddp
    solver --> sddp
    comm --> sddp
    stochastic --> sddp
    sddp --> cli

For the full dependency graph and crate responsibilities, see the methodology reference.

cobre-core

experimental

cobre-core is the shared data model for the Cobre ecosystem. It defines the fundamental entity types used across all crates: buses, transmission lines, hydro plants, thermal units, energy contracts, pumping stations, and non-controllable sources. Every other Cobre crate consumes cobre-core types by shared reference; no crate other than cobre-io constructs System values.

The crate has no solver, optimizer, or I/O dependencies. It holds pure data structures, the System container that groups them, derived topology graphs, penalty resolution utilities, temporal types, scenario pipeline types, initial conditions, generic constraints, and pre-resolved penalty/bound tables.

Module overview

Design principles

Clarity-first representation. cobre-core stores entities in the form most readable to a human engineer: nested JSON concepts are flattened into named fields with explicit unit suffixes, optional sub-models appear as Option<Enum> variants, and every f64 field carries a unit in its name and doc comment. Performance-adapted views (packed arrays, LP variable indices) live in downstream solver crates, not here.

Validate at construction. The SystemBuilder catches invalid states during construction – duplicate IDs, broken cross-references, cascade cycles, and invalid filling configurations – so the rest of the system receives a structurally sound System with no need for defensive checks at solve time.

Declaration-order invariance. Entity collections are stored in canonical ID-sorted order. Any System built from the same entities produces bit-for-bit identical results regardless of the order in which entities were supplied to SystemBuilder. Integration tests verify this property explicitly.

Thread-safe and immutable after construction. System is Send + Sync. After SystemBuilder::build() returns Ok, the System is immutable and can be shared across threads without synchronization.

Entity types

Fully modeled entities

These four entity types contribute LP variables and constraints in optimization and simulation procedures.

Bus

An electrical network node where power balance is maintained.

DeficitSegment has two fields: depth_mw: Option<f64> (the MW capacity of the segment; None for the final unbounded segment) and cost_per_mwh: f64 (the marginal cost in that segment). Segments are ordered by ascending cost. The final segment always has depth_mw = None to ensure LP feasibility.

Line

A transmission interconnection between two buses.

Line flow is a hard constraint; the exchange_cost is a regularization term, not a violation penalty.

Thermal

A thermal power plant with a piecewise-linear generation cost curve.

ThermalCostSegment holds capacity_mw: f64 and cost_per_mwh: f64. GnlConfig holds lag_stages: i32 (number of stages of dispatch anticipation for liquefied natural gas units that require advance scheduling).

Hydro

The most complex entity type: a hydroelectric plant with a reservoir, turbines, and optional cascade connectivity. It has 22 fields.

Identity and connectivity:

Reservoir and outflow:

Turbine:

Optional hydraulic sub-models:

Penalties:

Stub entities

These three entity types are data-complete but do not contribute LP variables or constraints in the minimal viable implementation. Their type definitions exist in the registry so analysis code can iterate over all entity types uniformly.

PumpingStation

Transfers water between hydro reservoirs while consuming electrical power. Fields: id, name, bus_id, source_hydro_id, destination_hydro_id, entry_stage_id, exit_stage_id, consumption_mw_per_m3s, min_flow_m3s, max_flow_m3s.

EnergyContract

A bilateral energy agreement with an entity outside the modeled system. Fields: id, name, bus_id, contract_type (ContractType::Import or ContractType::Export), entry_stage_id, exit_stage_id, price_per_mwh, min_mw, max_mw. Negative price_per_mwh represents export revenue.

NonControllableSource

Intermittent generation (wind, solar, run-of-river) that cannot be dispatched. Fields: id, name, bus_id, entry_stage_id, exit_stage_id, max_generation_mw, curtailment_cost (pre-resolved).

Supporting types

Enums

ConstantProductivity is used universally and is the minimal viable model. LinearizedHead is for high-fidelity analyses where head-dependent terms matter. Fpha is the full production function with head-area-productivity tables for detailed modeling.

Structs

EntityId

EntityId is a newtype wrapper around i32:

#![allow(unused)]
fn main() {
#[derive(Debug, Clone, Copy, PartialEq, Eq, Hash)]
pub struct EntityId(pub i32);
}

Why i32, not String. All JSON entity schemas use integer IDs. Integer keys are cheaper to hash, compare, and copy than strings. EntityId appears in every lookup index and cross-reference field, so this is a high-frequency type. If a future input format requires string IDs, the newtype boundary isolates the change to EntityId’s internal representation and its From/Into impls.

Why no Ord. Entity ordering is always by inner i32 value (canonical ID order), but the spec deliberately omits Ord to prevent accidental use of lexicographic ordering in contexts that expect ID-based ordering. Sort sites use sort_by_key(|e| e.id.0) explicitly, making the intent visible at each call site.

Construction and conversion:

#![allow(unused)]
fn main() {
use cobre_core::EntityId;

let id: EntityId = EntityId::from(42);
let raw: i32 = i32::from(id);
assert_eq!(id.to_string(), "42");
}

System and SystemBuilder

System is the top-level in-memory representation of a validated, resolved case. It is produced by SystemBuilder (directly in tests) and by cobre-io::load_case() in production. It is consumed read-only by downstream solver and analysis crates.

#![allow(unused)]
fn main() {
use cobre_core::{Bus, DeficitSegment, EntityId, SystemBuilder};

let system = SystemBuilder::new()
    .buses(vec![Bus {
        id: EntityId(1),
        name: "Main Bus".to_string(),
        deficit_segments: vec![],
        excess_cost: 0.0,
    }])
    .build()
    .expect("valid system");

assert_eq!(system.n_buses(), 1);
assert!(system.bus(EntityId(1)).is_some());
}

Validation in SystemBuilder::build()

SystemBuilder::build() runs four validation phases in order:

1. Duplicate check. Each of the 7 entity collections is scanned for duplicate EntityId values. All collections are checked before returning. If any duplicates are found, build() returns early with the error list.

2. Cross-reference validation. Every foreign-key field is verified against the appropriate collection index. Checked fields include bus_id on hydros, thermals, pumping stations, energy contracts, and non-controllable sources; source_bus_id and target_bus_id on lines; downstream_id and diversion.downstream_id on hydros; and source_hydro_id and destination_hydro_id on pumping stations. All broken references across all entity types are collected; build() returns early after this phase if any are found.

3. Cascade topology and cycle detection. CascadeTopology is built from the validated hydro downstream_id fields. If the topological sort (Kahn’s algorithm) does not reach all hydros, the unvisited hydros form a cycle. Their IDs are reported in a ValidationError::CascadeCycle error. Filling configurations are also validated in this phase.

4. Filling config validation. Each hydro with a FillingConfig must have a positive filling_inflow_m3s and a non-None entry_stage_id. Violations produce ValidationError::InvalidFillingConfig errors.

If all phases pass, build() constructs NetworkTopology, builds O(1) lookup indices for all 7 collections, and returns the immutable System.

The build() signature collects and returns all errors found across all collections rather than short-circuiting on the first failure:

#![allow(unused)]
fn main() {
pub fn build(self) -> Result<System, Vec<ValidationError>>
}

Canonical ordering

Before building indices, SystemBuilder::build() sorts every entity collection by entity.id.0. The resulting System stores entities in this canonical order. All accessor methods (buses(), hydros(), etc.) return slices in canonical order. This guarantees declaration-order invariance: two System values built from the same entities in different input orders are structurally identical.

Topology

CascadeTopology

CascadeTopology represents the directed forest of hydro plant cascade relationships. It is built from the downstream_id fields of all hydro plants and stored on System.

#![allow(unused)]
fn main() {
let cascade = system.cascade();

// Downstream plant for a given hydro (None if terminal).
let ds: Option<EntityId> = cascade.downstream(EntityId(1));

// All upstream plants for a given hydro (empty slice if headwater).
let upstream: &[EntityId] = cascade.upstream(EntityId(3));

// Topological ordering: every upstream plant appears before its downstream.
let order: &[EntityId] = cascade.topological_order();

cascade.is_headwater(EntityId(1)); // true if no upstream plants
cascade.is_terminal(EntityId(3));  // true if no downstream plant
}

The topological order is computed using Kahn’s algorithm with a sorted ready queue, ensuring determinism: within the same topological level, hydros appear in ascending ID order.

NetworkTopology

NetworkTopology provides O(1) lookups for bus-line incidence and bus-to-entity maps. It is built from all entity collections and stored on System.

#![allow(unused)]
fn main() {
let network = system.network();

// Lines connected to a bus.
let connections: &[BusLineConnection] = network.bus_lines(EntityId(1));
// BusLineConnection has `line_id: EntityId` and `is_source: bool`.

// Generators connected to a bus.
let generators: &BusGenerators = network.bus_generators(EntityId(1));
// BusGenerators has `hydro_ids`, `thermal_ids`, `ncs_ids` (all Vec<EntityId>).

// Load entities connected to a bus.
let loads: &BusLoads = network.bus_loads(EntityId(1));
// BusLoads has `contract_ids` and `pumping_station_ids` (both Vec<EntityId>).
}

All ID lists in BusGenerators and BusLoads are in canonical ascending-ID order for determinism.

Penalty resolution

Penalty values are resolved from a three-tier cascade: global defaults, entity-level overrides, and stage-level overrides. The first two tiers are implemented in Phase 1. Stage-varying overrides are deferred to Phase 2.

GlobalPenaltyDefaults holds system-wide fallback values for all penalty fields:

#![allow(unused)]
fn main() {
pub struct GlobalPenaltyDefaults {
    pub bus_deficit_segments: Vec<DeficitSegment>,
    pub bus_excess_cost: f64,
    pub line_exchange_cost: f64,
    pub hydro: HydroPenalties,
    pub ncs_curtailment_cost: f64,
}
}

The five resolution functions each accept an optional entity-level override and the global defaults, returning the resolved value:

#![allow(unused)]
fn main() {
// Returns entity segments if present, else global defaults.
let segments = resolve_bus_deficit_segments(&entity_override, &global);

// Returns entity value if Some, else global default.
let cost    = resolve_bus_excess_cost(entity_override, &global);
let cost    = resolve_line_exchange_cost(entity_override, &global);
let cost    = resolve_ncs_curtailment_cost(entity_override, &global);

// Resolves all 11 hydro penalty fields field-by-field.
let hydro_p = resolve_hydro_penalties(&entity_overrides, &global);
}

HydroPenalties holds 11 pre-resolved f64 fields:

The optional HydroPenaltyOverrides struct mirrors HydroPenalties with all fields as Option<f64>. It is an intermediate type used during case loading; the resolved HydroPenalties (with no Options) is what is stored on each Hydro entity.

Validation errors

ValidationError is the error type returned by SystemBuilder::build():

All variants implement Display and the standard Error trait. The error message includes the entity type, the offending ID, and (for reference errors) the field name and the missing referenced ID.

#![allow(unused)]
fn main() {
use cobre_core::{EntityId, ValidationError};

let err = ValidationError::InvalidReference {
    source_entity_type: "Hydro",
    source_id: EntityId(3),
    field_name: "bus_id",
    referenced_id: EntityId(99),
    expected_type: "Bus",
};
// "Hydro with id 3 has invalid cross-reference in field 'bus_id': referenced Bus id 99 does not exist"
println!("{err}");
}

Temporal model

The temporal module defines the time structure of a multi-stage stochastic optimization problem. These types are loaded from stages.json by cobre-io and stored on System.

There are 13 types in total: 5 enums and 8 structs.

Enums

BlockMode::Parallel is the default: blocks are independent sub-periods solved simultaneously, with water balance aggregated across all blocks in the stage. BlockMode::Chronological enables intra-stage storage dynamics (daily cycling).

PolicyGraphType::FiniteHorizon is the minimal viable solver choice: an acyclic stage chain with zero terminal value. Cyclic requires a positive annual_discount_rate for convergence.

Block

A load block within a stage, representing a sub-period with uniform demand and generation characteristics.

The block weight (fraction of stage duration) is derived on demand as duration_hours / sum(all block hours in stage) and is not stored.

StageStateConfig

Flags controlling which variables carry state between stages.

inflow_lags must be true when the PAR model order p > 0 and inflow lag cuts are enabled.

ScenarioSourceConfig

Per-stage scenario generation configuration.

branching_factor is the per-stage branching factor for both the opening tree and the forward pass. noise_method is orthogonal to SamplingScheme (which selects the forward-pass noise source); it governs how the backward-pass opening tree is produced.

Stage

A single stage in the multi-stage stochastic problem, partitioning the study horizon into decision periods.

Pre-study stages (negative id) carry only id, start_date, end_date, and season_id. Their blocks, risk_config, and scenario_config fields are unused.

#![allow(unused)]
fn main() {
use chrono::NaiveDate;
use cobre_core::temporal::{
    Block, BlockMode, NoiseMethod, ScenarioSourceConfig, Stage,
    StageRiskConfig, StageStateConfig,
};

let stage = Stage {
    index: 0,
    id: 1,
    start_date: NaiveDate::from_ymd_opt(2024, 1, 1).unwrap(),
    end_date:   NaiveDate::from_ymd_opt(2024, 2, 1).unwrap(),
    season_id:  Some(0),
    blocks: vec![Block {
        index: 0,
        name: "SINGLE".to_string(),
        duration_hours: 744.0,
    }],
    block_mode: BlockMode::Parallel,
    state_config: StageStateConfig { storage: true, inflow_lags: false },
    risk_config: StageRiskConfig::Expectation,
    scenario_config: ScenarioSourceConfig {
        branching_factor: 50,
        noise_method: NoiseMethod::Saa,
    },
};
}

SeasonDefinition and SeasonMap

Season definitions map season IDs to calendar periods for PAR model coefficient lookup and inflow history aggregation.

SeasonDefinition fields:

SeasonMap groups the definitions with a cycle type:

Transition and PolicyGraph

Transition represents a directed edge in the policy graph:

PolicyGraph is the top-level clarity-first representation of the stage graph loaded from stages.json:

For finite horizon, transitions form a linear chain. For cyclic horizon, at least one transition has source_id >= target_id (a back-edge) and the annual_discount_rate must be positive for convergence.

#![allow(unused)]
fn main() {
use cobre_core::temporal::{PolicyGraph, PolicyGraphType, Transition};

let graph = PolicyGraph {
    graph_type: PolicyGraphType::FiniteHorizon,
    annual_discount_rate: 0.06,
    transitions: vec![
        Transition { source_id: 1, target_id: 2, probability: 1.0,
                     annual_discount_rate_override: None },
        Transition { source_id: 2, target_id: 3, probability: 1.0,
                     annual_discount_rate_override: Some(0.08) },
    ],
    season_map: None,
};
assert_eq!(graph.graph_type, PolicyGraphType::FiniteHorizon);
}

The solver-level HorizonMode enum in cobre-sddp is built from a PolicyGraph at initialization time; it precomputes transition maps, cycle detection, and discount factors for efficient runtime dispatch. The PolicyGraph in cobre-core is the user-facing clarity-first representation.

Scenario pipeline types

The scenario module holds clarity-first data containers for the raw scenario pipeline parameters loaded from input files. These are raw input-facing types; performance-adapted views (pre-computed LP arrays, Cholesky-decomposed matrices) belong in downstream crates (cobre-stochastic, cobre-sddp).

SamplingScheme and ScenarioSource

SamplingScheme selects the forward-pass noise source:

InSample is the default and the minimal viable solver choice.

ScenarioSource is the top-level scenario configuration loaded from stages.json:

ExternalSelectionMode has two variants: Random (draw uniformly at random) and Sequential (replay in file order, cycling when the end is reached).

InflowModel

Raw PAR(p) model parameters for a single (hydro, stage) pair, loaded from inflow_seasonal_stats.parquet and inflow_ar_coefficients.parquet.

#![allow(unused)]
fn main() {
use cobre_core::{EntityId, scenario::InflowModel};

let model = InflowModel {
    hydro_id: EntityId(1),
    stage_id: 3,
    mean_m3s: 150.0,
    std_m3s: 30.0,
    ar_order: 2,
    ar_coefficients: vec![0.45, 0.22],
};
assert_eq!(model.ar_order, 2);
assert_eq!(model.ar_coefficients.len(), 2);
}

System holds a Vec<InflowModel> sorted by (hydro_id, stage_id) for declaration-order invariance.

LoadModel

Raw load seasonal statistics for a single (bus, stage) pair, loaded from load_seasonal_stats.parquet.

Load typically has no AR structure, so no lag coefficients are stored. System holds a Vec<LoadModel> sorted by (bus_id, stage_id).

CorrelationModel

CorrelationModel is the top-level correlation configuration loaded from correlation.json. It holds named profiles and an optional stage-to-profile schedule.

The type hierarchy is:

CorrelationModel
  └── profiles: BTreeMap<String, CorrelationProfile>
        └── groups: Vec<CorrelationGroup>
              ├── entities: Vec<CorrelationEntity>
              └── matrix: Vec<Vec<f64>>   (symmetric, row-major)

CorrelationEntity carries entity_type: String (currently always "inflow") and id: EntityId. Using String rather than an enum preserves forward compatibility when additional stochastic variable types are added.

profiles uses BTreeMap rather than HashMap to preserve deterministic iteration order (declaration-order invariance). Cholesky decomposition of the correlation matrices is NOT performed here; that belongs to cobre-stochastic.

#![allow(unused)]
fn main() {
use std::collections::BTreeMap;
use cobre_core::{EntityId, scenario::{
    CorrelationEntity, CorrelationGroup, CorrelationModel, CorrelationProfile,
}};

let mut profiles = BTreeMap::new();
profiles.insert("default".to_string(), CorrelationProfile {
    groups: vec![CorrelationGroup {
        name: "All".to_string(),
        entities: vec![
            CorrelationEntity { entity_type: "inflow".to_string(), id: EntityId(1) },
            CorrelationEntity { entity_type: "inflow".to_string(), id: EntityId(2) },
        ],
        matrix: vec![vec![1.0, 0.8], vec![0.8, 1.0]],
    }],
});

let model = CorrelationModel {
    method: "cholesky".to_string(),
    profiles,
    schedule: vec![],
};
assert!(model.profiles.contains_key("default"));
}

When schedule is empty, a single profile (typically named "default") applies to all stages. When schedule is non-empty, each entry maps a stage index to an active profile name.

Initial conditions and constraints

InitialConditions

InitialConditions holds the reservoir storage levels at the start of the study. It is loaded from initial_conditions.json by cobre-io and stored on System.

Two arrays are kept separate because filling hydros can have an initial volume below dead storage (min_storage_hm3), which is not a valid operating level for regular hydros:

HydroStorage carries hydro_id: EntityId and value_hm3: f64. A hydro must appear in exactly one of the two arrays. Both arrays are sorted by hydro_id after loading for declaration-order invariance.

#![allow(unused)]
fn main() {
use cobre_core::{EntityId, InitialConditions, HydroStorage};

let ic = InitialConditions {
    storage: vec![
        HydroStorage { hydro_id: EntityId(0), value_hm3: 15_000.0 },
        HydroStorage { hydro_id: EntityId(1), value_hm3:  8_500.0 },
    ],
    filling_storage: vec![
        HydroStorage { hydro_id: EntityId(10), value_hm3: 200.0 },
    ],
};

assert_eq!(ic.storage.len(), 2);
assert_eq!(ic.filling_storage.len(), 1);
}

GenericConstraint

GenericConstraint represents a user-defined linear constraint over LP variables, loaded from generic_constraints.json and stored in System::generic_constraints. The expression parser (string to ConstraintExpression) and referential validation live in cobre-io, not here.

ConstraintExpression holds a Vec<LinearTerm>. Each LinearTerm has a coefficient: f64 and a variable: VariableRef.

VariableRef

VariableRef is an enum with 19 variants covering all LP variable types defined in the data model. Each variant names the variable type and carries the entity ID. For block-specific variables, block_id is None to sum over all blocks or Some(i) to reference block i specifically.

HydroStorage, HydroEvaporation, and HydroWithdrawal are stage-level variables (no block_id). All other hydro variables and all thermal, line, bus, pumping, contract, and NCS variables are block-specific (block_id field present).

SlackConfig

Controls whether a soft constraint with a penalty cost is added to the LP:

#![allow(unused)]
fn main() {
use cobre_core::{
    EntityId, GenericConstraint, ConstraintExpression, ConstraintSense,
    LinearTerm, SlackConfig, VariableRef,
};

let expr = ConstraintExpression {
    terms: vec![
        LinearTerm {
            coefficient: 1.0,
            variable: VariableRef::HydroGeneration {
                hydro_id: EntityId(10),
                block_id: None,   // sum over all blocks
            },
        },
        LinearTerm {
            coefficient: 1.0,
            variable: VariableRef::HydroGeneration {
                hydro_id: EntityId(11),
                block_id: None,
            },
        },
    ],
};

let gc = GenericConstraint {
    id: EntityId(0),
    name: "min_hydro_total".to_string(),
    description: Some("Minimum total hydro generation".to_string()),
    expression: expr,
    sense: ConstraintSense::GreaterEqual,
    slack: SlackConfig { enabled: true, penalty: Some(5_000.0) },
};

assert_eq!(gc.expression.terms.len(), 2);
}

Resolved penalties and bounds

The resolved module holds pre-resolved penalty and bound tables that provide O(1) lookup for LP builders and solvers.

Design: flat Vec with 2D indexing

During input loading, the three-tier cascade (global defaults -> entity overrides -> stage overrides) is evaluated once by cobre-io. The results are stored in flat Vec<T> arrays with manual 2D indexing:

data[entity_idx * n_stages + stage_idx]

This layout gives cache-friendly sequential access when iterating over stages for a fixed entity (the common inner loop pattern in LP construction). No re-evaluation of the cascade is ever required at solve time; every penalty or bound lookup is a single array index operation.

ResolvedPenalties

ResolvedPenalties holds per-(entity, stage) penalty values for all four entity types that carry stage-varying penalties: hydros, buses, lines, and non-controllable sources.

Per-(entity, stage) penalty structs:

Bus deficit segments are NOT stage-varying. The piecewise-linear deficit structure is fixed at the entity or global level, so BusStagePenalties contains only excess_cost.

All four per-stage penalty structs implement Copy, so they can be passed by value on hot paths.

#![allow(unused)]
fn main() {
use cobre_core::resolved::{
    BusStagePenalties, HydroStagePenalties, LineStagePenalties,
    NcsStagePenalties, ResolvedPenalties,
};

// Allocate a 3-hydro, 2-bus, 1-line, 1-ncs table for 5 stages.
let table = ResolvedPenalties::new(
    3, 2, 1, 1, 5,
    HydroStagePenalties { spillage_cost: 0.01, diversion_cost: 0.02,
                          fpha_turbined_cost: 0.03,
                          storage_violation_below_cost: 1000.0,
                          filling_target_violation_cost: 5000.0,
                          turbined_violation_below_cost: 500.0,
                          outflow_violation_below_cost: 500.0,
                          outflow_violation_above_cost: 500.0,
                          generation_violation_below_cost: 500.0,
                          evaporation_violation_cost: 500.0,
                          water_withdrawal_violation_cost: 500.0 },
    BusStagePenalties { excess_cost: 100.0 },
    LineStagePenalties { exchange_cost: 5.0 },
    NcsStagePenalties { curtailment_cost: 50.0 },
);

// O(1) lookup: hydro 1, stage 3
let p = table.hydro_penalties(1, 3);
assert!((p.spillage_cost - 0.01).abs() < f64::EPSILON);
}

ResolvedBounds

ResolvedBounds holds per-(entity, stage) bound values for five entity types: hydros, thermals, lines, pumping stations, and energy contracts.

Per-(entity, stage) bound structs:

HydroStageBounds has 11 fields:

#![allow(unused)]
fn main() {
use cobre_core::resolved::{
    ContractStageBounds, HydroStageBounds, LineStageBounds,
    PumpingStageBounds, ResolvedBounds, ThermalStageBounds,
};

// Allocate a table for 2 hydros, 1 thermal, 1 line, 0 pumping, 0 contracts, 3 stages.
let table = ResolvedBounds::new(
    2, 1, 1, 0, 0, 3,
    HydroStageBounds { min_storage_hm3: 10.0, max_storage_hm3: 200.0,
                       min_turbined_m3s: 0.0,  max_turbined_m3s: 500.0,
                       min_outflow_m3s: 5.0,   max_outflow_m3s: None,
                       min_generation_mw: 0.0, max_generation_mw: 100.0,
                       max_diversion_m3s: None,
                       filling_inflow_m3s: 0.0, water_withdrawal_m3s: 0.0 },
    ThermalStageBounds { min_generation_mw: 50.0, max_generation_mw: 400.0 },
    LineStageBounds { direct_mw: 1000.0, reverse_mw: 800.0 },
    PumpingStageBounds { min_flow_m3s: 0.0, max_flow_m3s: 0.0 },
    ContractStageBounds { min_mw: 0.0, max_mw: 0.0, price_per_mwh: 0.0 },
);

// O(1) lookup: hydro 0, stage 2
let b = table.hydro_bounds(0, 2);
assert!((b.max_storage_hm3 - 200.0).abs() < f64::EPSILON);
assert!(b.max_outflow_m3s.is_none());
}

Both tables expose _mut accessor variants (e.g., hydro_penalties_mut, hydro_bounds_mut) that return &mut T for in-place updates during case loading. These are used exclusively by cobre-io; all other crates use the immutable read accessors.

Serde feature flag

cobre-core ships with an optional serde feature that enables serde::Serialize and serde::Deserialize for all public types. The feature is disabled by default to keep the minimal build free of serialization dependencies.

When to enable

Enabling the feature

# Cargo.toml
[dependencies]
cobre-core = { version = "0.x", features = ["serde"] }

Or from the command line:

cargo build --features cobre-core/serde

Enabling serde also activates chrono/serde, which is required because Stage carries NaiveDate fields that must be serializable for JSON input loading and MPI broadcast.

How it works

Every public type in cobre-core carries a #[cfg_attr(feature = "serde", derive(serde::Serialize, serde::Deserialize))] attribute. When the feature is inactive, the derive is omitted entirely and the serde dependency is not compiled. There is no runtime cost and no API surface change when the feature is disabled.

All downstream Cobre crates that perform serialization declare cobre-core/serde as a required dependency. The workspace ensures that only one copy of cobre-core is compiled, with the feature union of all crates that request it.

Public API summary

System exposes four categories of methods:

Collection accessors (return &[T] in canonical ID order): buses(), lines(), hydros(), thermals(), pumping_stations(), contracts(), non_controllable_sources()

Count queries (return usize): n_buses(), n_lines(), n_hydros(), n_thermals(), n_pumping_stations(), n_contracts(), n_non_controllable_sources()

Entity lookup by ID (return Option<&T>): bus(id), line(id), hydro(id), thermal(id), pumping_station(id), contract(id), non_controllable_source(id) – each is O(1) via a HashMap<EntityId, usize> index into the canonical collection.

Topology accessors (return references to derived structures): cascade() returns &CascadeTopology, network() returns &NetworkTopology.

For full method signatures and rustdoc, run:

cargo doc --workspace --no-deps --open

For the theoretical underpinning of the entity model, generation models, and penalty system, see the methodology reference.

cobre-io

experimental

cobre-io is the case directory loader for the Cobre ecosystem. It provides the load_case function, which reads a case directory from disk and produces a fully-validated [cobre_core::System] ready for use by downstream solver and analysis crates.

The crate owns the entire input path: JSON and Parquet parsing, five layers of validation, three-tier penalty and bound resolution, and scenario model assembly. No other crate reads input files. Every crate downstream of cobre-io receives a structurally sound System with all foreign keys resolved and all domain rules verified.

Module overview

load_case

#![allow(unused)]
fn main() {
pub fn load_case(path: &Path) -> Result<System, LoadError>
}

Loads a power system case directory and returns a fully-validated System.

path must point to the case root directory. That directory must contain config.json, penalties.json, stages.json, initial_conditions.json, the system/ subdirectory, the scenarios/ subdirectory, and the constraints/ subdirectory. See Case directory structure for the full layout.

load_case executes the following sequence:

1. Layer 1 — Structural validation. Checks that all required files exist on disk and records which optional files are present. Missing required files produce [LoadError::ConstraintError] entries. Missing optional files are silently noted in the file manifest without error.
2. Layer 2 — Schema validation. Parses every present file, verifies required fields, types, and value ranges. Returns [LoadError::IoError] for read failures and [LoadError::ParseError] for malformed JSON or invalid Parquet. Schema violations produce [LoadError::ConstraintError] entries.
3. Layer 3 — Referential integrity. Verifies that every cross-entity ID reference resolves to a known entity. Dangling foreign keys produce [LoadError::ConstraintError] entries.
4. Layer 4 — Dimensional consistency. Checks that optional per-entity files provide coverage for every entity that needs them (for example, that inflow statistical parameters exist for every hydro plant). Coverage gaps produce [LoadError::ConstraintError] entries.
5. Layer 5 — Semantic validation. Enforces domain business rules: acyclic hydro cascade topology, penalty ordering (lower tiers may not exceed upper), PAR model stationarity, stage count consistency. Violations produce [LoadError::ConstraintError] entries.
6. Resolution. After all five layers pass, three-tier penalty and bound resolution is performed. The result is pre-resolved lookup tables embedded in the System for O(1) solver access.
7. Scenario assembly. Inflow and load statistical models are assembled from the parsed seasonal statistics and autoregressive coefficients.
8. System construction. SystemBuilder::build() is called with the fully resolved data. Any remaining structural violations (duplicate IDs, broken cascade) surface as a final [LoadError::ConstraintError].

All validation diagnostics across Layers 1 through 5 are collected by ValidationContext before failing. When load_case returns an error, the error message contains every problem found, not just the first one.

Minimal example

#![allow(unused)]
fn main() {
use cobre_io::load_case;
use std::path::Path;

let system = load_case(Path::new("path/to/my_case"))?;
println!("Loaded {} buses, {} hydros", system.n_buses(), system.n_hydros());
}

Return type

On success, load_case returns a cobre_core::System — an immutable, Send + Sync container holding all entity registries, topology graphs, pre-resolved penalty and bound tables, scenario models, and the stage sequence. All entity collections are in canonical ID-sorted order.

On failure, load_case returns a LoadError. See Error handling for the full set of variants and when each occurs.

Case directory structure

A valid case directory has the following layout:

my_case/
├── config.json                          # Solver configuration (required)
├── penalties.json                       # Global penalty defaults (required)
├── stages.json                          # Stage sequence and policy graph (required)
├── initial_conditions.json              # Reservoir storage at study start (required)
├── system/
│   ├── buses.json                       # Electrical buses (required)
│   ├── lines.json                       # Transmission lines (required)
│   ├── hydros.json                      # Hydro plants (required)
│   ├── thermals.json                    # Thermal plants (required)
│   ├── non_controllable_sources.json    # Intermittent sources (optional)
│   ├── pumping_stations.json            # Pumping stations (optional)
│   └── energy_contracts.json           # Bilateral contracts (optional)
├── extensions/
│   ├── hydro_geometry.parquet           # Reservoir geometry tables (optional)
│   ├── production_models.json           # FPHA production function configs (optional)
│   └── fpha_hyperplanes.parquet         # FPHA hyperplane coefficients (optional)
├── scenarios/
│   ├── inflow_seasonal_stats.parquet    # PAR model seasonal statistics (required)
│   ├── inflow_ar_coefficients.parquet   # PAR autoregressive coefficients (required)
│   ├── inflow_history.parquet           # Historical inflow series (optional)
│   ├── load_seasonal_stats.parquet      # Load model seasonal statistics (optional)
│   ├── load_factors.parquet             # Load scaling factors (optional)
│   ├── correlation.json                 # Cross-series correlation model (optional)
│   └── external_scenarios.parquet       # Pre-generated external scenarios (optional)
└── constraints/
    ├── hydro_bounds.parquet             # Stage-varying hydro bounds (optional)
    ├── thermal_bounds.parquet           # Stage-varying thermal bounds (optional)
    ├── line_bounds.parquet              # Stage-varying line bounds (optional)
    ├── pumping_bounds.parquet           # Stage-varying pumping bounds (optional)
    ├── contract_bounds.parquet          # Stage-varying contract bounds (optional)
    ├── generic_constraints.json         # User-defined LP constraints (optional)
    ├── generic_constraint_bounds.parquet # Bounds for generic constraints (optional)
    ├── exchange_factors.parquet         # Block exchange factors (optional)
    ├── penalty_overrides_hydro.parquet  # Stage-varying hydro penalty overrides (optional)
    ├── penalty_overrides_bus.parquet    # Stage-varying bus penalty overrides (optional)
    ├── penalty_overrides_line.parquet   # Stage-varying line penalty overrides (optional)
    └── penalty_overrides_ncs.parquet    # Stage-varying NCS penalty overrides (optional)

For the full JSON and Parquet schemas for each file, see the Case Format Reference.

Validation pipeline

The five layers run in sequence. Earlier layers gate later ones: if Layer 1 finds a missing required file, the file is not parsed in Layer 2. All diagnostics across all layers are collected before returning.

Case directory
      │
      ▼
┌─────────────────────────────────────────────────┐
│  Layer 1 — Structural                           │
│  Does each required file exist on disk?         │
│  Records optional-file presence in FileManifest.│
└────────────────────┬────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────┐
│  Layer 2 — Schema                               │
│  Parse JSON and Parquet. Check required fields, │
│  types, and value ranges. Collect schema errors.│
└────────────────────┬────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────┐
│  Layer 3 — Referential integrity                │
│  All cross-entity ID references must resolve.   │
│  (e.g., hydro.bus_id must exist in buses list)  │
└────────────────────┬────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────┐
│  Layer 4 — Dimensional consistency              │
│  Optional per-entity files must cover every     │
│  entity that needs them. (e.g., inflow stats    │
│  must exist for every hydro plant)              │
└────────────────────┬────────────────────────────┘
                     │
                     ▼
┌─────────────────────────────────────────────────┐
│  Layer 5 — Semantic                             │
│  Domain business rules: acyclic cascade,        │
│  penalty ordering, PAR stationarity, stage      │
│  count consistency, and other invariants.       │
└────────────────────┬────────────────────────────┘
                     │
                     ▼ (all layers pass)
              Resolution + Assembly
              System construction
                     │
                     ▼
              Ok(System)

What each layer checks

Layer 1 (Structural): Verifies that the four root-level required files (config.json, penalties.json, stages.json, initial_conditions.json) and the four required entity files (system/buses.json, system/lines.json, system/hydros.json, system/thermals.json) exist. Optional files are noted in the FileManifest but their absence is not an error. The FileManifest is passed to Layer 2 so that optional-file parsers are only called when the files are present.

Layer 2 (Schema): Parses every file found by Layer 1. For JSON files, deserialization uses serde with strict field requirements — missing required fields and unknown field values surface immediately. For Parquet files, column presence and data types are verified. Post-deserialization checks catch domain range violations (for example, negative capacity values) that serde cannot express. All parse and schema errors are collected by ValidationContext.

Layer 3 (Referential integrity): Checks all cross-entity foreign-key references. Examples: every hydro.bus_id must name a bus in the bus registry; every line.source_bus_id and line.target_bus_id must resolve; every pumping_station.source_hydro_id and destination_hydro_id must resolve; every bound override row’s entity ID must match a known entity. All broken references are collected before returning.

Layer 4 (Dimensional consistency): Verifies cross-file entity coverage. When scenarios/inflow_seasonal_stats.parquet is present, every hydro plant must have at least one row of statistics. When scenarios/inflow_ar_coefficients.parquet is present, the AR order must be consistent with the number of coefficient rows. Other coverage checks ensure that optional per-entity Parquet files do not silently omit entities.

Layer 5 (Semantic): Enforces domain invariants that span multiple files or require reasoning about the system as a whole:

• Acyclic cascade. The hydro downstream_id graph must be a directed forest (no cycles). A topological sort detects cycles.
• Penalty ordering. Violation penalty tiers must be ordered: lower-tier penalties may not exceed upper-tier penalties for the same entity.
• PAR model stationarity. Seasonal inflow statistics must satisfy the stationarity requirements of the PAR(p) model.
• Stage count consistency. The number of stages must match across stages.json, scenario data, and any stage-varying Parquet files.

Penalty and bound resolution

After all five validation layers pass, load_case resolves the three-tier penalty and bound cascades into flat lookup tables embedded in the System.

Three-tier cascade

Penalty and bound values follow a three-tier precedence cascade:

Tier 1 — Global defaults (penalties.json)
    ↓ overridden by
Tier 2 — Entity-level overrides (system/*.json fields)
    ↓ overridden by
Tier 3 — Stage-varying overrides (constraints/penalty_overrides_*.parquet)

Tier-1 and tier-2 resolution happen during entity parsing (Layer 2). By the time the resolution step runs, each entity struct already holds its tier-2 resolved value in the relevant penalty or bound field.

The resolution step applies tier-3 stage-varying overrides from the optional Parquet files. For each (entity, stage) pair, the resolved value is:

• The tier-3 override from the Parquet row, if a row exists for that pair.
• Otherwise, the tier-2 value already stored in the entity struct.

Sparse expansion

Tier-3 overrides are stored sparsely: a Parquet row only needs to exist for stages where the override differs from the entity-level value. The resolution step expands this sparse representation into a dense [n_entities × n_stages] array for O(1) solver lookup at construction time.

Result

Resolution produces two pre-resolved tables stored on System:

• ResolvedPenalties — per-(entity, stage) penalty values for buses, hydros, lines, and non-controllable sources.
• ResolvedBounds — per-(entity, stage) upper and lower bound values for hydros, thermals, lines, pumping stations, and energy contracts.

Both tables use dense flat arrays with positional entity indexing (entity position in the canonical ID-sorted slice becomes its array index).

Config struct

Config is the in-memory representation of config.json. Use parse_config to load it independently of load_case:

#![allow(unused)]
fn main() {
use cobre_io::config::parse_config;
use std::path::Path;

let cfg = parse_config(Path::new("my_case/config.json"))?;
println!("forward_passes = {:?}", cfg.training.forward_passes);
}

Config has six sections:

Mandatory fields

Two fields in training have no defaults and must be present in config.json. parse_config returns LoadError::SchemaError if either is absent:

• training.forward_passes — number of scenario trajectories per iteration (integer, >= 1)
• training.stopping_rules — list of stopping rule entries (must include at least one iteration_limit rule)

Stopping rules

The training.stopping_rules array accepts four rule types, identified by the "type" field:

Multiple rules combine according to training.stopping_mode: "any" (default, OR semantics — stop when any rule triggers) or "all" (AND semantics — stop only when all rules trigger simultaneously).

Policy modes

The policy.mode field controls warm-start behavior:

When mode is "warm_start" or "resume", load_case also validates policy compatibility: the stored policy’s entity counts, stage count, and cut dimensions must match the current case. Mismatches return LoadError::PolicyIncompatible.

Error handling

All errors returned by load_case and its internal parsers are variants of LoadError:

IoError

I/O error reading {path}: {source}

Occurs when a required file exists in the file manifest but cannot be read from disk (file not found, permission denied, or other OS-level I/O failure). Fields: path: PathBuf (the file that failed) and source: std::io::Error (the underlying error).

When it occurs: Layer 1 or Layer 2, when std::fs::read_to_string or a Parquet reader returns an error for a required file.

ParseError

parse error in {path}: {message}

Occurs when a file is readable but its content is malformed — invalid JSON syntax, unexpected end of input, or an unreadable Parquet column header. Fields: path: PathBuf and message: String (description of the parse failure).

When it occurs: Layer 2, during initial deserialization of JSON or Parquet files before any field-level validation runs.

SchemaError

schema error in {path}, field {field}: {message}

Occurs when a file parses successfully but a field violates a schema constraint: a required field is missing, a value is outside its valid range, or an enum discriminator names an unknown variant. Fields: path: PathBuf, field: String (dot-separated path to the offending field, e.g., "hydros[3].bus_id"), and message: String.

When it occurs: Layer 2, during post-deserialization validation. Also returned by parse_config when training.forward_passes or training.stopping_rules is absent.

CrossReferenceError

cross-reference error: {source_entity} in {source_file} references
non-existent {target_entity} in {target_collection}

Occurs when an entity ID field references an entity that does not exist in the expected registry. Fields: source_file: PathBuf, source_entity: String (e.g., "Hydro 'H1'"), target_collection: String (e.g., "bus registry"), and target_entity: String (e.g., "BUS_99").

When it occurs: Layer 3 (referential integrity). All broken references across all entity types are collected before returning.

ConstraintError

constraint violation: {description}

A catch-all for collected validation errors from any of the five layers, and for SystemBuilder::build() rejections. The description field contains all error messages joined by newlines, each prefixed with its [ErrorKind], source file, optional entity identifier, and message text.

When it occurs: After any validation layer collects one or more error-severity diagnostics, or when SystemBuilder::build() finds duplicate IDs or a cascade cycle in the final construction step.

PolicyIncompatible

policy incompatible: {check} mismatch — policy has {policy_value},
system has {system_value}

Occurs when a warm-start or resume policy file is structurally incompatible with the current case. The four compatibility checks are: hydro count, stage count, cut dimension, and entity identity hash. Fields: check: String (name of the failing check), policy_value: String, and system_value: String.

When it occurs: After all five validation layers pass, when policy.mode is "warm_start" or "resume" and the stored policy fails a compatibility check.

Design notes

Collect-all validation. Unlike parsers that short-circuit on the first error, all five validation layers collect diagnostics into a shared ValidationContext before failing. When load_case returns a ConstraintError, the description field contains every problem found in a single report. This avoids the frustrating fix-one-error-re-run-repeat cycle on large cases.

File-format split. Entity identity data (IDs, names, topology, static parameters) lives in JSON. Time-varying and per-stage data (bounds, penalty overrides, statistical parameters, scenarios) lives in Parquet. JSON is easy to read and edit by hand; Parquet handles large numeric tables efficiently. The two formats complement each other without overlap.

Resolution separates concerns. The three-tier cascade is resolved once at load time into dense arrays, not at every solver call. Downstream solver crates call system.penalties().hydro(entity_idx, stage_idx) and get an f64 with no branching, no hash lookups, and no tier logic. The complexity of the cascade is entirely contained in cobre-io.

Declaration-order invariance. All entity collections are sorted by ID before SystemBuilder::build() is called. Any System built from the same entities, regardless of the order they appear in the input files, produces a structurally identical result with identical pre-resolved tables.

cobre-stochastic

experimental

cobre-stochastic provides the stochastic process models for the Cobre power systems ecosystem. It builds probabilistic representations of hydro inflow time series — using Periodic Autoregressive (PAR(p)) models — and generates correlated noise scenarios for use by iterative scenario-based optimization algorithms. The crate is solver-agnostic: it supplies fully-initialized stochastic infrastructure components that any scenario-based iterative optimization algorithm can consume read-only, with no dependency on any particular solver vertical.

The crate has no dependency on cobre-solver or cobre-comm. It depends only on cobre-core for entity types and on a small set of RNG and hashing crates for deterministic noise generation.

Module overview

Architecture

PAR(p) preprocessing and flat array layout

PAR(p) (Periodic Autoregressive) models describe the seasonal autocorrelation structure of hydro inflow time series. Each hydro plant at each stage has an InflowModel with a mean (mean_m3s), a standard deviation (std_m3s), and a vector of AR coefficients in standardized form (ar_coefficients).

PrecomputedParLp is built once at initialization from raw InflowModel parameters. It converts AR coefficients from standardized form (ψ*, direct Yule-Walker output) to original-unit form at build time:

ψ_{m,ℓ} = ψ*_{m,ℓ} · s_m / s_{m-ℓ}

where s_m is std_m3s for the current stage’s season and s_{m-ℓ} is std_m3s for the season ℓ stages prior. The converted coefficients and their derived intercepts (base) are stored in stage-major flat arrays:

array[stage * n_hydros + hydro]          (2-D: means, stds, base terms)
psi[stage * n_hydros * max_order + hydro * max_order + lag]  (3-D: AR coefficients)

This layout ensures that all per-stage data for every hydro plant is contiguous in memory, maximizing cache utilization during sequential stage iteration within a scenario trajectory.

All hot-path arrays use Box<[f64]> (via Vec::into_boxed_slice()) rather than Vec<f64>. The boxed-slice type communicates the no-resize invariant and eliminates the capacity word from each allocation.

Deterministic noise via SipHash-1-3 seed derivation (DEC-017)

Each scenario realization in an iterative optimization run requires a draw from the noise distribution. Rather than broadcasting seeds across compute nodes — which would require communication — each node independently derives its own seed from a small tuple using SipHash-1-3 (DEC-017).

Two derivation functions are provided:

• derive_forward_seed(base_seed, iteration, scenario, stage) -> u64: hashes a 20-byte little-endian wire format base_seed (8B) ++ iteration (4B) ++ scenario (4B) ++ stage (4B).
• derive_opening_seed(base_seed, opening_index, stage) -> u64: hashes a 16-byte wire format base_seed (8B) ++ opening_index (4B) ++ stage (4B).

The different wire lengths provide domain separation without explicit prefixes, preventing hash collisions between forward-pass seeds and opening-tree seeds. stage in both functions is always stage.id (the domain identifier), never stage.index (the array position), because array positions shift under stage filtering while IDs are stable.

From the derived seed, a Pcg64 RNG is constructed via rng_from_seed. The PCG family provides good statistical quality with fast generation, suitable for producing large numbers of standard-normal samples via the StandardNormal distribution.

Cholesky-based spatial correlation

Hydro inflow series at neighboring plants are spatially correlated. cobre-stochastic applies a Cholesky transformation to convert independent standard-normal samples into correlated samples.

The Cholesky decomposition is hand-rolled using the Cholesky-Banachiewicz algorithm (~150 lines). No external linear algebra crate is added to the dependency tree. The lower-triangular factor L (such that Sigma = L * L^T) is stored in packed lower-triangular format: element (i, j) with j <= i is at index i*(i+1)/2 + j. This eliminates the zero upper-triangle entries and halves memory usage.

Correlation profiles can be defined per-season. DecomposedCorrelation holds all profiles in a BTreeMap<String, Vec<GroupFactor>> — the BTreeMap guarantees deterministic iteration order, which is required for declaration-order invariance.

Before entering the hot optimization loop, callers must invoke DecomposedCorrelation::resolve_positions(&mut self, entity_order: &[EntityId]) once. This pre-computes the positions of each group’s entities within the canonical entity order and stores them on each GroupFactor as Option<Box<[usize]>>. With positions pre-computed, apply_correlation avoids a per-call O(n) linear scan and heap allocation on the hot path.

If a correlation group’s entity IDs are only partially present in entity_order, the Cholesky transform is skipped for that group entirely. Entities not in any group retain their independent noise values unchanged.

Opening tree structure

The opening scenario tree pre-generates all noise realizations used during the backward pass of the optimization algorithm, before the iterative loop begins. This avoids per-iteration recomputation and ensures the backward pass always operates on a fixed, reproducible set of scenarios.

OpeningTree stores all noise values in a single flat contiguous array with stage-major ordering:

data[stage_offsets[stage] + opening_idx * dim .. + dim]

The stage_offsets array has length n_stages + 1. The sentinel entry stage_offsets[n_stages] equals data.len(), making bounds checks exact without special-casing the last stage. This sentinel pattern is used consistently in PrecomputedParLp, OpeningTree, and throughout StochasticContext.

Pre-study stages (those with negative stage.id) are excluded from the opening tree but remain in inflow_models for PAR lag initialization.

StochasticContext as the integration entry point

StochasticContext bundles the three independently-built components into a single ready-to-use value:

1. PrecomputedParLp — PAR coefficient cache for LP RHS patching.
2. DecomposedCorrelation — pre-decomposed Cholesky factors for all profiles.
3. OpeningTree — pre-generated noise realizations for the backward pass.

build_stochastic_context(&system, base_seed) runs the full preprocessing pipeline in a fixed order: validate PAR parameters, build the coefficient cache, decompose correlation matrices, generate the opening tree. After construction, all fields are immutable. StochasticContext is Send + Sync, verified by a compile-time assertion and a unit test.

sample_forward for InSample scenario selection

sample_forward implements the InSample scenario selection strategy: for each (iteration, scenario, stage) triple, it deterministically selects one opening from the tree by deriving a seed via derive_forward_seed and sampling a Pcg64 RNG. The selected opening index and its noise slice are returned together, so the caller can both log which opening was chosen and immediately use the noise values.

Public types

StochasticContext

Owns all three preprocessing pipeline outputs: PrecomputedParLp, DecomposedCorrelation, and OpeningTree. Constructed by build_stochastic_context and then consumed read-only. Accessors: par_lp(), correlation(), opening_tree(), tree_view(), base_seed(), dim(), n_stages(). Both Send and Sync.

PrecomputedParLp

Cache-friendly PAR(p) model data for LP RHS patching. Stores means, standard deviations, original-unit AR coefficients (ψ), and intercept terms (base) in stage-major flat arrays (Box<[f64]>). Built via PrecomputedParLp::build. Accessors: n_hydros(), n_stages(), max_order(), mean(), std(), base(), psi().

DecomposedCorrelation

Holds Cholesky-decomposed correlation factors for all profiles, keyed by profile name in a BTreeMap. Built via DecomposedCorrelation::build, which validates and decomposes all profiles eagerly — errors surface at initialization, not at per-stage lookup time. Call resolve_positions once with the canonical entity order before entering the optimization loop.

OpeningTree

Fixed opening scenario tree holding pre-generated noise realizations. All noise values are in a flat Box<[f64]> with stage-major ordering and a sentinel offset array of length n_stages + 1. Provides opening(stage_idx, opening_idx) -> &[f64] for element access and view() -> OpeningTreeView<'_> for a zero-copy borrowed view.

OpeningTreeView<'a>

A zero-copy borrowed view over an OpeningTree, with the same accessor API: opening(stage_idx, opening_idx), n_stages(), n_openings(stage_idx), dim(). Passed to sample_forward to avoid cloning the tree data.

StochasticError

Returned by all fallible APIs. Five variants:

Implements std::error::Error, Send, and Sync.

ParValidationReport

Return type of validate_par_parameters. Contains a list of ParWarning values for non-fatal issues (e.g., high AR coefficients that may indicate numerical instability) that the caller can inspect or log before proceeding to PrecomputedParLp::build.

ParWarning

A non-fatal PAR parameter warning. Carries the hydro ID, stage ID, and a human-readable description of the potential issue.

GroupFactor

A single correlation group’s Cholesky factor with its associated entity ID mapping. Fields: factor: CholeskyFactor, entity_ids: Vec<EntityId>, and pre-computed positions: Option<Box<[usize]>> (filled by resolve_positions).

CholeskyFactor

The lower-triangular Cholesky factor L of a correlation matrix, stored in packed row-major form. Element (i, j) with j <= i is at index i*(i+1)/2 + j. Constructed via CholeskyFactor::decompose(&matrix) and applied via transform(&input, &mut output).

Usage example

The following shows how to construct a stochastic context from a loaded system and use it to sample a forward-pass scenario.

#![allow(unused)]
fn main() {
use cobre_stochastic::{
    build_stochastic_context,
    sampling::insample::sample_forward,
};

// `system` is a `cobre_core::System` produced by `cobre_io::load_case`.
// `base_seed` comes from the study configuration (application layer handles
// the Option<i64> -> u64 conversion and OS-entropy fallback).
let ctx = build_stochastic_context(&system, base_seed)?;

println!(
    "stochastic context: {} hydros, {} study stages",
    ctx.dim(),
    ctx.n_stages(),
);

// Obtain a borrowed view over the opening tree (zero-copy).
let tree_view = ctx.tree_view();

// In the iterative optimization loop, select a forward scenario for each
// (iteration, scenario, stage) triple.
let iteration: u32 = 0;
let scenario: u32 = 0;

for (stage_idx, stage) in study_stages.iter().enumerate() {
    // stage.id is the domain identifier; stage_idx is the array position.
    let (opening_idx, noise_slice) = sample_forward(
        &tree_view,
        ctx.base_seed(),
        iteration,
        scenario,
        stage.id as u32,
        stage_idx,
    );

    // `noise_slice` has length `ctx.dim()` (one value per hydro plant).
    // Pass to LP RHS patching together with `ctx.par_lp()`.
    let _ = (opening_idx, noise_slice);
}
Ok::<(), cobre_stochastic::StochasticError>(())
}

Performance notes

cobre-stochastic is designed so that all performance-critical preprocessing happens once at initialization. The iterative optimization loop consumes already-materialized data through slice indexing, with no re-allocation on the hot path.

Pre-computed entity positions (resolve_positions)

DecomposedCorrelation::resolve_positions must be called once before entering the optimization loop. It pre-computes the mapping from each correlation group’s entity IDs to their positions in the canonical entity_order slice and stores the result as Option<Box<[usize]>> on each GroupFactor. Without this pre-computation, apply_correlation would perform an O(n) linear scan and a Vec allocation for every noise draw.

Stack-allocated buffers for small groups (MAX_STACK_DIM = 64)

Inside apply_correlation, intermediate working buffers for correlation groups with at most 64 entities are stack-allocated (using arrayvec or a fixed-size array on the stack). Groups larger than this threshold fall back to heap-allocated Vec. The fast path covers the overwhelming majority of practical correlation groups, eliminating heap allocation from the inner loop for typical study configurations.

Incremental row_base in Cholesky transform

The packed lower-triangular storage index for element (i, j) is i*(i+1)/2 + j. Rather than recomputing the triangular index from scratch for each row, the transform method maintains an incremental row_base variable that is incremented by i+1 at the end of each row. This eliminates a multiplication per row iteration on the hot path of the Cholesky forward substitution.

Box<[f64]> for the no-resize invariant

All fixed-size hot-path arrays in PrecomputedParLp, OpeningTree, and CholeskyFactor use Box<[f64]> rather than Vec<f64>. The boxed-slice type communicates that these arrays are immutable after construction, eliminates the capacity word from each allocation, and allows the optimizer to treat the length as a compile-time-stable bound.

Feature flags

cobre-stochastic has no optional feature flags. All dependencies are always compiled. No external system libraries are required (HiGHS, MPI, etc.).

# Cargo.toml
cobre-stochastic = { version = "0.1" }

Testing

Running the test suite

cargo test -p cobre-stochastic

No external dependencies or system libraries are required. All dependencies (siphasher, rand, rand_pcg, rand_distr, thiserror) are Cargo-managed. The --all-features flag is not needed — there are no feature flags.

Test suite overview

The crate has 125 tests total: 105 unit tests, 5 conformance integration tests, 4 reproducibility integration tests, and 11 doc-tests.

Conformance suite (tests/conformance.rs)

The conformance test suite verifies the PAR(p) preprocessing pipeline against hand-computed fixtures with known exact outputs.

Two fixtures are used:

• AR(0) fixture: a zero-order AR model (pure noise, no lagged terms). The precomputed psi array must be all-zeros and the base values must equal the raw means. Tolerance: 1e-10.
• AR(1) fixture: a first-order AR model with a pre-study stage (negative stage.id) that supplies the lag mean and standard deviation for coefficient unit conversion. The conversion formula ψ = ψ* · s_m / s_lag is tested against a hand-computed value. Tolerance: 1e-10.

Reproducibility suite (tests/reproducibility.rs)

Four tests verify the determinism and invariance properties that are required for correct behavior in a distributed, multi-run setting:

• Seed determinism: calling derive_forward_seed and derive_opening_seed with the same inputs always returns bitwise-identical seeds. Golden-value regression pins the exact hash output for a known (base_seed, ...) tuple.
• Opening tree seed sensitivity: different base_seed values produce different opening trees (verified by checking that at least one noise value differs across the full tree). Uses any() over all tree entries rather than assert_ne! on the whole tree, to handle the astronomically unlikely case where two seeds produce one identical value.
• Declaration-order invariance: inserting hydros in reversed order into a SystemBuilder (which sorts by EntityId internally) produces a StochasticContext with bitwise-identical PAR arrays, opening tree, and Cholesky transform output. This verifies the canonical-order invariant across the full preprocessing pipeline.
• Infrastructure genericity gate: a grep audit confirms that no algorithm-specific references appear anywhere in the crate source tree. The gate is encoded as a #[test] using std::process::Command so it runs automatically in CI.

Design notes

Communication-free noise generation (DEC-017)

The original design considered broadcasting a seed from the root rank to all workers before each iteration. DEC-017 rejected this approach because it adds an MPI collective on the hot path and creates a serialization point as the number of ranks grows.

The alternative — deriving each rank’s seeds independently from a common base_seed plus a context tuple — requires no communication and produces identical results regardless of the number of ranks. SipHash-1-3 was chosen because it is non-cryptographic (fast), produces high-quality 64-bit hashes suitable for seeding a CSPRNG, and is available in the siphasher crate with no system dependencies.

The two wire formats (20 bytes for forward seeds, 16 bytes for opening seeds) use length-based domain separation rather than an explicit prefix byte, which is slightly more efficient and equally correct given that the two sets of input tuples have different shapes and lengths.

cobre-solver

experimental

cobre-solver is the LP solver abstraction layer for the Cobre ecosystem. It defines a backend-agnostic interface for constructing, solving, and querying linear programs, with a production-grade HiGHS backend as the default implementation.

The crate has no dependency on any other Cobre crate. It is infrastructure that optimization algorithm crates consume through a generic type parameter, not a shared registry or runtime-selected component. Every solver method call compiles directly to the concrete backend implementation — there is no virtual dispatch overhead on the hot path where iterative LP solving occurs.

Module overview

The ffi and highs modules are compiled only when the highs feature is enabled (the default). The trait_def and types modules are always compiled, making it possible to write algorithm code against SolverInterface without depending on any particular backend.

Architecture

Compile-time monomorphization (DEC-002)

SolverInterface is resolved as a generic type parameter at compile time, not as Box<dyn SolverInterface> or any other form of dynamic dispatch. An optimization algorithm crate parameterizes its entry point as:

#![allow(unused)]
fn main() {
fn run<S: SolverInterface>(solver_factory: impl Fn() -> S, ...) { ... }
}

The compiler generates one concrete implementation per backend. The HiGHS backend is the only active backend in a standard build; the binary contains no solver-selection branch. This is specified in DEC-002 and implemented in ADR-003.

Custom FFI — not highs-sys

cobre-solver does not use any third-party highs-sys crate. Instead it ships a thin C wrapper (csrc/highs_wrapper.c) that exposes the 20-odd HiGHS C API functions needed by the backend as cobre_highs_* symbols. This approach:

• Controls exactly which HiGHS API surface is exposed.
• Allows the wrapper to enforce Cobre-specific invariants before delegating to the underlying Highs_* calls.
• Avoids a build-time dependency on any external Rust crate for FFI bindings.

The ffi module declares extern "C" signatures for each cobre_highs_* function. All FFI calls are unsafe; safe wrappers live in highs.rs.

Vendored HiGHS build

HiGHS is compiled from source at build time via the cmake crate. The source lives in crates/cobre-solver/vendor/HiGHS/ as a git submodule. The build script (crates/cobre-solver/build.rs) invokes cmake with a fixed Release configuration and links the resulting static library. HiGHS is always built in Release mode regardless of the Cargo profile, because a debug HiGHS build is roughly 10x slower and would produce misleading performance results.

Per-crate unsafe override

The workspace lint configuration forbids unsafe code at the workspace level. cobre-solver overrides this lint to allow in its own Cargo.toml because the HiGHS FFI layer genuinely requires unsafe blocks. All other workspace lints (missing_docs, unwrap_used, clippy pedantic) remain active. Every unsafe block carries a // SAFETY: comment explaining the invariants that justify it.

SolverInterface trait

#![allow(unused)]
fn main() {
pub trait SolverInterface: Send { ... }
}

The trait defines 10 methods that together constitute the full LP lifecycle for one solver instance. Implementations must satisfy the pre- and post-condition contracts documented in each method’s rustdoc. See the trait_def rustdoc for the complete contracts.

Method summary

Mutability convention

Methods that mutate solver state — loading a model, adding constraints, patching bounds, solving, resetting, and extracting a basis — take &mut self. get_basis requires &mut self because it writes to internal scratch buffers during extraction. Methods that only read accumulated state (statistics, name) take &self. This convention makes data-race hazards visible at the type level: the borrow checker prevents concurrent mutation without locks.

Error recovery contract

When solve or solve_with_basis returns Err, the solver’s internal state is unspecified. The caller is responsible for calling reset() before reusing the instance. Failing to reset after a terminal error may produce incorrect results or panics on the next load_model call.

Thread safety

SolverInterface requires Send but not Sync. Send allows a solver instance to be transferred to a worker thread at startup. The absence of Sync prevents concurrent access from multiple threads, which matches the reality of C-library solver handles: they maintain mutable factorization workspaces that are not thread-safe. Each worker thread owns exactly one solver instance.

Public types

StageTemplate

Pre-assembled structural LP for one stage, in CSC (column-major) form. Built once at initialization from resolved internal structures and shared read-only across all threads. Passed to load_model to bulk-load the LP. Fields include the CSC matrix arrays (col_starts, row_indices, values), bounds, objective coefficients, and layout metadata (n_state, n_transfer, n_dual_relevant, n_hydro, max_par_order) used by the calling algorithm for state transfer and cut extraction. See the StageTemplate rustdoc.

RowBatch

Batch of constraint rows for addition to a loaded LP, in CSR (row-major) form. Assembled from an active constraint pool before each LP rebuild and passed to add_rows in a single call. Appended rows occupy the dynamic constraint region of the LP matrix. See the RowBatch rustdoc.

Basis

Raw simplex basis stored as solver-native i32 status codes — one per column and one per row. The codes are opaque to the calling algorithm; they are extracted from one solve via get_basis and passed back to the next via solve_with_basis for warm-starting. Stored in the original (unpresolved) problem space for portability across solver versions and presolve strategies. When the LP gains new dynamic constraint rows after a basis was saved, solve_with_basis handles the dimension mismatch by filling new row slots with the solver-native “Basic” code. See the Basis rustdoc.

SolutionView<'a>

Zero-copy borrowed view over solver-internal buffers, returned by solve and solve_with_basis. Provides objective(), primal(), dual(), reduced_costs(), iterations(), and solve_time_seconds() as slice references into the solver’s internal arrays. The view borrows the solver and is valid until the next &mut self call. Call to_owned() to copy the data into an LpSolution when the solution must outlive the borrow. See the SolutionView rustdoc.

LpSolution

Owned solution produced by SolutionView::to_owned(): objective (f64, minimization sense), primal (Vec of column values), dual (Vec of row dual multipliers, normalized to the canonical sign convention), reduced_costs, iterations, and solve_time_seconds. Dual values are normalized before the struct is returned — HiGHS row duals are already in the canonical convention and require no negation. See the LpSolution rustdoc.

SolverError

Terminal LP solve error returned after all retry attempts are exhausted. Six variants correspond to six failure categories:

Infeasible and Unbounded are unit variants (no fields). NumericalDifficulty carries a message, TimeLimitExceeded carries elapsed_seconds, and IterationLimit carries iterations. InternalError carries message and an optional error_code. See the SolverError rustdoc.

SolverStatistics

Accumulated solve metrics for one solver instance: solve_count, success_count, failure_count, total_iterations, retry_count, total_solve_time_seconds, and basis_rejections. All counters grow monotonically from zero. reset() does not zero them — statistics persist for the lifetime of the solver instance and are aggregated across threads after iterative solving completes. See the SolverStatistics rustdoc.

HiGHS backend (HighsSolver)

Construction

#![allow(unused)]
fn main() {
pub fn new() -> Result<Self, SolverError>
}

HighsSolver::new() allocates a HiGHS handle via cobre_highs_create() and applies seven performance-tuned default options before returning:

If HiGHS handle creation or any option call fails, the handle is destroyed before returning Err(SolverError::InternalError { .. }).

5-level retry escalation

When HiGHS returns SOLVE_ERROR or UNKNOWN (not a definitive terminal status), HighsSolver::solve escalates through five retry levels before giving up:

The first level that returns OPTIMAL exits the loop. If a definitive terminal status (INFEASIBLE, UNBOUNDED, TIME_LIMIT, ITERATION_LIMIT) is reached during a retry level, the loop exits immediately with the corresponding SolverError variant. If all five levels are exhausted without a result, the method returns SolverError::NumericalDifficulty. Default settings are restored unconditionally after the retry loop, regardless of outcome, so subsequent calls see the standard configuration.

The retry sequence is entirely internal — the caller of solve never sees intermediate failures, only the final Ok(LpSolution) or Err(SolverError).

Dual normalization

HiGHS row duals are already in the canonical Cobre sign convention: a positive dual on a <= constraint means increasing the RHS increases the objective. HighsSolver::extract_solution copies row_dual directly into LpSolution.dual without negation. The col_dual from HiGHS is the reduced cost vector and is placed in LpSolution.reduced_costs.

Warm-start basis management

solve_with_basis loads the Basis status codes directly into HiGHS via Highs_setBasis. When the saved basis has fewer rows than the current LP (because new dynamic constraint rows were added since the basis was extracted), the extra rows are filled with the HiGHS “Basic” status code (1). When the saved basis has more rows than the current LP, the extra entries are truncated. If HiGHS rejects the basis (returns HIGHS_STATUS_ERROR from Highs_setBasis), the method falls back to a cold-start solve and increments SolverStatistics.basis_rejections. After setting the basis, solve_with_basis delegates to solve(), which handles the retry escalation sequence.

SoA bound patching (DEC-019)

The set_row_bounds and set_col_bounds methods take three separate slices:

#![allow(unused)]
fn main() {
fn set_row_bounds(&mut self, indices: &[usize], lower: &[f64], upper: &[f64]);
fn set_col_bounds(&mut self, indices: &[usize], lower: &[f64], upper: &[f64]);
}

This is a Structure of Arrays (SoA) signature. The alternative — a single slice of (usize, f64, f64) tuples (Array of Structures, AoS) — would require the caller to convert from its natural SoA representation before the call, and the HiGHS C API (Highs_changeRowsBoundsBySet) would then expect SoA again, producing a double conversion on the hottest solver path.

DEC-019 documents the rationale: the calling algorithm naturally holds separate index, lower-bound, and upper-bound arrays; the C API expects separate arrays; so the trait signature matches both, eliminating any intermediate conversion. The performance impact is meaningful because bound patching happens at every scenario realization, which occurs on the innermost loop of iterative LP solving.

Usage example

The following shows the complete LP rebuild sequence for one stage: load the structural model, append active constraint rows, patch scenario-specific row bounds, solve, and extract the basis for the next iteration.

use cobre_solver::{
    Basis, HighsSolver, LpSolution, RowBatch, SolverError,
    SolverInterface, StageTemplate,
};

fn solve_stage(
    solver: &mut HighsSolver,
    template: &StageTemplate,
    cuts: &RowBatch,
    row_indices: &[usize],
    lower: &[f64],
    upper: &[f64],
    cached_basis: Option<&Basis>,
    basis_buf: &mut Basis,
) -> Result<LpSolution, SolverError> {
    // Step 1: load structural LP (replaces any prior model).
    solver.load_model(template);

    // Step 2: append active constraint rows.
    solver.add_rows(cuts);

    // Step 3: patch row bounds for this scenario realization.
    solver.set_row_bounds(row_indices, lower, upper);

    // Step 4: solve, optionally warm-starting from a cached basis.
    let view = match cached_basis {
        Some(basis) => solver.solve_with_basis(basis)?,
        None => solver.solve()?,
    };

    // Step 5: copy the zero-copy view into an owned solution.
    let solution = view.to_owned();

    // Step 6: extract basis into the caller-owned buffer for warm-starting.
    solver.get_basis(basis_buf);

    Ok(solution)
}

fn main() -> Result<(), SolverError> {
    let mut solver = HighsSolver::new()?;
    assert_eq!(solver.name(), "HiGHS");

    // Print cumulative statistics after a run.
    let stats = solver.statistics();
    println!(
        "solves={} successes={} retries={}",
        stats.solve_count, stats.success_count, stats.retry_count
    );

    Ok(())
}

Build requirements

Git submodule

HiGHS is vendored as a git submodule at crates/cobre-solver/vendor/HiGHS/. Before building cobre-solver for the first time (or after a fresh clone), initialize the submodule:

git submodule update --init --recursive

The build script checks for crates/cobre-solver/vendor/HiGHS/CMakeLists.txt and panics with a clear error message if the submodule is not initialized.

System dependencies

Feature flags

Without the highs feature, only SolverInterface, the type definitions, and the ffi module stubs are compiled. The HighsSolver struct is not available. Additional solver backends (CLP, commercial solvers) are planned behind their own feature flags but are not yet implemented.

Testing

Running the test suite

cargo test -p cobre-solver --features highs

This requires cmake, a C/C++ compiler, and an initialized crates/cobre-solver/vendor/HiGHS/ submodule (see Build requirements).

Conformance suite (tests/conformance.rs)

The integration test file tests/conformance.rs implements the backend-agnostic conformance contract from the Solver Interface Testing spec. It verifies the SolverInterface contract using only the public API against the HighsSolver concrete type. The fixture LP is a 3-variable, 2-constraint minimization problem (the SS1.1 fixture) with known optimal solution (x0=6, x1=0, x2=2, obj=100.0).

The conformance suite covers:

• load_model loads a structural LP and produces the expected objective and primal values on solve.
• load_model fully replaces a previous model when called a second time.
• add_rows appends constraint rows without altering structural rows.
• set_row_bounds patches bounds and the re-solve reflects the new bounds.
• solve_with_basis warm-starts successfully and returns the correct optimal solution.
• get_basis returns a basis with the correct column and row count after a successful solve.
• statistics counters increment correctly across solve calls.
• reset clears model state, allowing load_model to be called again cleanly.

Unit tests

src/highs.rs and src/types.rs carry #[cfg(test)] unit tests covering individual methods in isolation, including the NoopSolver in src/trait_def.rs that verifies SolverInterface compiles as a generic bound and satisfies the Send requirement.

cobre-comm

experimental

cobre-comm is the pluggable communication backend abstraction for the Cobre ecosystem. It defines the Communicator and SharedMemoryProvider traits that decouple distributed computations from specific communication technologies, allowing solver crates to run unchanged in single-process, MPI-distributed, and future TCP or shared-memory configurations.

The crate currently provides two concrete backends:

• local — single-process backend, always available, zero overhead, zero external dependencies.
• mpi — MPI backend via ferrompi, feature-gated behind features = ["mpi"].

Two additional backend slots are reserved for future implementation:

• tcp — TCP/IP coordinator pattern (no MPI required).
• shm — POSIX shared memory for single-node multi-process execution.

The factory function create_communicator selects the backend at startup based on Cargo feature flags and an optional environment variable override. Downstream solver crates depend on the Communicator trait through a generic type parameter — never on a concrete backend type.

Module overview

Communicator trait

#![allow(unused)]
fn main() {
pub trait Communicator: Send + Sync { ... }
}

The trait provides the six operations used during distributed computations: four collective operations and two infallible accessor methods. The trait is intentionally not object-safe — it carries generic methods (allgatherv<T>, allreduce<T>, broadcast<T>) that require static dispatch. This is the same monomorphization pattern used by SolverInterface in cobre-solver: callers parameterize a generic function once and the compiler generates one concrete instantiation per backend.

Since a Cobre binary uses exactly one communicator backend (MPI for distributed execution, LocalBackend for single-process mode), the binary contains only one instantiation per generic call site. The performance benefit is meaningful: LocalBackend’s no-op implementations compile to zero instructions after inlining.

Method summary

Design: compile-time static dispatch (DEC-001)

Writing Box<dyn Communicator> does not compile — the trait is intentionally not object-safe. All callers use a generic type parameter:

#![allow(unused)]
fn main() {
use cobre_comm::{Communicator, CommError};

fn print_topology<C: Communicator>(comm: &C) {
    println!("rank {} of {}", comm.rank(), comm.size());
}
}

This is the mandated pattern for closed variant sets in Cobre (DEC-001). The dispatch overhead for CommBackend is a single branch-predictor-friendly integer comparison, negligible compared to the cost of the MPI collective operation or LP solve it wraps.

Thread safety

Communicator requires Send + Sync. All collective methods take &self (shared reference). Callers are responsible for serializing concurrent calls — the training loop ensures that multiple threads never invoke the same collective simultaneously on the same communicator instance. rank() and size() are safe to call concurrently: their values are cached at construction time and never change.

SharedMemoryProvider trait

#![allow(unused)]
fn main() {
pub trait SharedMemoryProvider: Send + Sync { ... }
}

SharedMemoryProvider is a companion trait to Communicator for managing intra-node shared memory regions. It is a separate trait rather than a supertrait of Communicator, which preserves flexibility: not all backends support true shared memory. Functions that only need collective communication use C: Communicator; functions that additionally need shared memory use C: Communicator + SharedMemoryProvider.

HeapRegion — the minimal viable region type

For the minimal viable implementation, all backends use HeapRegion<T> as their SharedMemoryProvider::Region<T> type. HeapRegion<T> is a thin wrapper around Vec<T>: each rank holds its own private heap allocation with no actual memory sharing between processes. The three-phase lifecycle (allocation, population, read-only) degenerates to simple Vec operations, with fence() a no-op.

True shared memory via MPI windows or POSIX shared memory segments is planned for a future optimization phase.

LocalCommunicator — object-safe intra-node coordination

LocalCommunicator is a purpose-built object-safe sub-trait that exposes only the three non-generic methods needed for intra-node initialization coordination:

#![allow(unused)]
fn main() {
use cobre_comm::LocalCommunicator;

fn determine_leader(local_comm: &dyn LocalCommunicator) -> bool {
    local_comm.rank() == 0
}
}

SharedMemoryProvider::split_local returns Box<dyn LocalCommunicator> — an intra-node communicator used only during initialization (leader/follower role assignment). Because this is an initialization-only operation far off the hot path, dynamic dispatch is the correct trade-off, and LocalCommunicator is the bridge that makes it possible without compromising the zero-cost static dispatch of the hot-path Communicator trait.

LocalBackend

#![allow(unused)]
fn main() {
pub struct LocalBackend;
}

LocalBackend is a zero-sized type (ZST) with no runtime state and no external dependencies. All collective operations use identity-copy or no-op semantics:

• rank() always returns 0.
• size() always returns 1.
• allgatherv copies send into recv at the specified displacement (identity copy — with one rank, gather is trivial).
• allreduce copies send to recv unchanged (reduction of a single operand is the identity).
• broadcast is a no-op (data is already at the only rank).
• barrier is a no-op (nothing to synchronize).

Because LocalBackend is a ZST, it occupies zero bytes at runtime and has no construction cost. Its collective method implementations compile to zero instructions after inlining in single-feature builds.

Example

#![allow(unused)]
fn main() {
use cobre_comm::{LocalBackend, Communicator, ReduceOp};

let comm = LocalBackend;
assert_eq!(comm.rank(), 0);
assert_eq!(comm.size(), 1);

// allreduce with one rank: identity copy regardless of op.
let send = vec![1.0_f64, 2.0, 3.0];
let mut recv = vec![0.0_f64; 3];
comm.allreduce(&send, &mut recv, ReduceOp::Sum).unwrap();
assert_eq!(recv, send);
}

LocalBackend also implements SharedMemoryProvider with HeapRegion<T> as the region type, and LocalCommunicator for use in intra-node initialization code.

FerrompiBackend

FerrompiBackend is the MPI backend, powered by the ferrompi crate. It is only compiled when features = ["mpi"] is specified:

# Cargo.toml
cobre-comm = { version = "0.1", features = ["mpi"] }

FerrompiBackend wraps a ferrompi::Mpi environment handle and an MPI_COMM_WORLD communicator. Construction calls MPI_Init_thread with ThreadLevel::Funneled, matching the Cobre execution model where only the main thread issues MPI calls. When FerrompiBackend is dropped, the RAII guard calls MPI_Finalize automatically.

FerrompiBackend requires an MPI runtime to be installed on the system. If no MPI runtime is found, FerrompiBackend::new() returns Err(BackendError::InitializationFailed).

The unsafe impl Send + Sync on FerrompiBackend reflects the fact that ferrompi::Mpi is !Send + !Sync by default (using a PhantomData<*const ()> marker), but the Cobre RAII pattern guarantees that construction and finalization happen on the same thread, making the impl sound.

Factory function: create_communicator

#![allow(unused)]
fn main() {
pub fn create_communicator() -> Result<impl Communicator, BackendError>
}

create_communicator is the single entry point for constructing a communicator at startup. It selects the backend according to:

1. The COBRE_COMM_BACKEND environment variable (runtime override).
2. The Cargo features compiled into the binary (auto-detection).
3. A fallback to LocalBackend when no distributed backend is available or detected.

BackendKind enum

BackendKind is provided for library-mode callers (such as cobre-python or cobre-mcp) that need to select a backend programmatically rather than through environment variables:

COBRE_COMM_BACKEND environment variable

Auto-detection checks for the presence of MPI launcher environment variables (PMI_RANK, PMI_SIZE, OMPI_COMM_WORLD_RANK, OMPI_COMM_WORLD_SIZE, MPI_LOCALRANKID, SLURM_PROCID). If any of these is set, the factory attempts to initialize the MPI backend.

Example

#![allow(unused)]
fn main() {
use cobre_comm::{create_communicator, Communicator};

// With COBRE_COMM_BACKEND unset (auto-detect):
// - returns FerrompiBackend if launched via mpirun/mpiexec
// - returns LocalBackend otherwise
let comm = create_communicator().expect("backend selection failed");
println!("rank {} of {}", comm.rank(), comm.size());
}

When distributed features are compiled in, create_communicator returns a CommBackend enum that delegates each method call to the active concrete backend via a match. When no distributed features are compiled in, it returns LocalBackend directly.

CommBackend enum

CommBackend is the enum-dispatched communicator wrapper present in builds where at least one distributed backend feature (mpi, tcp, or shm) is compiled in. It implements both Communicator and SharedMemoryProvider by delegating each method to the active inner backend:

#![allow(unused)]
fn main() {
use cobre_comm::{create_communicator, Communicator};

// With COBRE_COMM_BACKEND=local, the factory returns CommBackend::Local.
let comm = create_communicator().expect("backend selection failed");
let send = [42.0_f64];
let mut recv = [0.0_f64];
comm.allgatherv(&send, &mut recv, &[1], &[0]).unwrap();
assert_eq!(recv[0], 42.0);
}

Error types

CommError

Returned by all fallible methods on Communicator and SharedMemoryProvider.

BackendError

Returned by create_communicator when the backend cannot be selected or initialized.

Deferred features

The following features are planned but not yet implemented:

• TCP backend ("tcp" feature): a TCP/IP coordinator pattern for distributed execution without requiring an MPI installation. Will follow the same Communicator trait interface.
• Shared memory backend ("shm" feature): POSIX shared memory for single-node multi-process execution with zero inter-process copy overhead. Will implement SharedMemoryProvider using POSIX shared memory segments or MPI shared windows rather than the current HeapFallback semantics.

Feature flags
